1 947593

ISSUE 1

VIP-9890AL-CB-IC

InformaCast® Compliant

Vandal Resistant IP Talkback Call Station

INTRODUCTION

The VIP-9890AL-CB-IC InformaCast Compliant

IP Talkback Call Station allows communication to

an InformaCast Server and SIP-enabled

telephone systems via an IP network. The

VIP-9890AL-CB-IC combines a rugged; weather-

resistant talkback paging horn with a vandal-

resistant enclosure, which is ideally suited for

high-noise, exposed environments.

SPECIFICATIONS

Access Methods

InformaCast Server Broadcasts

InformaCast SIP

Analog PBX via Valcom gateway

Valcom Multicast Page Group

SIP – enabled telephone system

Features

RJ-45 for network connection

1 Form C relay output

Network activity LEDs

Power over Ethernet (PoE) 802.3af

compatible

Dimensions/Weight

Speaker Assembly / Backbox:

10.0” H x 12.5" W x 4" D

(25.4cm H x 31.75cm W x 10.2cm D)

Weight: 10.75lbs. (4.89 kg)

Network Interface

1.62” H x 5.63” W x 3.45” D

(4.11 cm) x (14.30 cm) x (8.76 cm)

with brackets – 8.22” W (20.87 cm)

Weight: 2.10 lbs. (0.95 kg)

Nominal Specifications

Output Impedance: 45 Ohms

Output Level: 100 dB@ 4’ on axis

Relay Current: 1 AMP @ 24VDC

Nominal Power Requirements

Via 802.3af (PoE) Ethernet Switch Class 3

Environment

Network Interface

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Intercom Unit:

Suitable for indoor or outdoor installation

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Precautionary Designations

WARNING-To Reduce The Risk Of Fire Or

Electric Shock. Do Not Expose This

Apparatus To Rain Or Moisture.

• AVERTISSEMENT - Afin de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système à la

pluie ou à l'humidité.

•Apparatus shall not be exposed to dripping

or splashing and no objects filled with

liquids, such as vases, shall be placed on

the apparatus.

•L’appareil ne doit pas être exposé à des

égouttements et éclaboussures et aucun

Objet Rempli de liquide, comme vase, ne

doit être placé sur l’appareil.
