HYDRAERIES SMANUAL HYDRAULIC LIFT TRUCKS

A

SSEMBLY,USE, AND MAINTENANCE MANUAL

RECEIVING INSTRUCTIONS:

After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the packaging and

maintains the orientation of the product in the packaging; then inspect the product closely to determine whether it

sustained damage during transport. If damage is discovered during the inspection, immediately record a complete

description of the damage on the bill of lading. If the product is undamaged, discard the packaging.

NOTES:

1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the product is

used is exclusively the responsibility of the owner/end-user

2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:

a) Instructions in this manual; or b) information provided on labels affixed to the product. Neither is Vestil responsible for

any consequential damages sustained as a result of failing to exercise sound judgment while assembling, installing, using

or maintaining this product.

Table of Contents

Product Specifications…………………………………..………………………………………………………………………………………. 2

Signal Words….………………………………………………………………………………………………………………………………….. 3

Safety Recommendations………………………………………………………………..…...………………………………………………… 3

FIG. 1: HYDRA-2 exploded parts diagram & bill of materials……………………………………………………………………………….. 4

FIG. 2: HYDRA-4 exploded parts diagram & bill of materials……………………………………………………………………………….. 5

FIG. 3: HYDRA-HD exploded parts diagram & bill of materials…………………………………………………………………………….. 6

Function tests before use……………………………………………………………………………………………………………………….. 7

Operation instructions…………………………………………………………………………………………………………………………… 7 - 8

Inspections & Maintenance……………………………………………………………………………………………………………………... 9

Troubleshooting Guide………………………………………………………………………………………………………………………….. 10

Detailed Troubleshooting—Foot Pump………………………………………………………………………………………………………... 11-15

FIG. 4: Hydraulic System Diagram…………………………………………………………………………………………………………….. 15

Detailed explanation of Hydraulic System Operation………………………………………………………………………………………… 16

Label Placement Diagram……...……………………………………………………………………………………………………………….. 17

Limited Warranty…...……………………………………………………………………………………………………………………………. 18

VMCESTIL ANUFACTURING ORP.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail: sales@vestil.com

Produktspezifikationen
