FMDL-Series Single & Double Eagle Beak Fork-Mounted Drum Lifters

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely to determine whether

it sustained damage during transport. If damage is discovered, record a complete description of it on the bill

of lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance comply

with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels, and

accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be

contacted online at https://www.vestil.com/page-parts-request.php.

Electronic copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-

manuals.php.

TABLE OF CONTENTS

PAGE

Specifications……….……………............................................................................................................

2

Signal Words…………………..….............................................................................................................

2

Safety Instructions…………………..…….................................................................................................

2

FMDL-1 Exploded View and Bill of Materials…………………………………………………………...…..

3

FMDL-2 Exploded View and Bill of Materials….…....…........................................................................

4

FPDL-11-H Exploded View and Bill of Materials……….………………………………………………......

5

FPDL-8-L Exploded View and Bill of Materials……….….………………………………………………….

6

DFDL-3 Exploded View and Bill of Materials…………..........................................................................

7

Centers of Gravity Diagrams………….………………………………………………………………..….....

8, 9, 10, 16, 17

Using the Lifter.……………..…………………………………………………………………………….....…...

11

Record of Satisfactory Condition…………………………………………………………………………….

11 - 12

Inspections & Maintenance…...………………………………………………………………………….…..

12

Labeling Diagram…………………………….…………………………………………………………………

12

Optional Equipment……………………………………………………………………………………….…...

13, 14, 15, 16, 17

Limited Warranty…………………………………………………………………………………………...……

18

Vestil Manufacturing Company

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestil.com[email protected]

Produktspezifikationen
