Seite 1/1
All data subject to change without notice.
05/18/21 PDS-24C708AF-1 Rev B
See Software Manual for more details
Excellence.
Every day. Every time.
www.videologyinc.com
HEADQUARTERS LOCATION
Videology Industrial-Grade Cameras
35 Hampden Road
Mansfi eld, MA 02048 | United States
EUROPE LOCATION
Videology Industrial-Grade Cameras
High Tech Campus 5
5656 AE Eindhoven | The Netherlands
24C708AF-1
Image Sensor Size 1/2.7"
Pixel Size 3 m x 3 mμ μ
Resolution
and Frame
Rates
MJPEG
compressed
Still Capture choices 1920x1080
(recommended)
1280 x 1024
1280x720
640x480
YUY2
uncompressed
Video Capture
choices. Still image
not possible
1920x1080/5fps
1280 x 1024/10fps
1280x720/20fps
640x480/30fps
Sensitivity 0.1LUX/F2.0
Signal to Noise Ratio >65dB
Shutter Mode Electronic rolling shutter
Field of View (H x V) 40° x 30°
Video Output USB 2.0
Power Supply 5VDC via USB 2.0 bus
Power Consumption <200mA
UVC Controls
Still Capture Selectable
Flash Selectable via Videology viewer or TWAIN
Focus Manual
Preset for 4-8 feet
Image Controls Contrast, Brightness, Hue, Resolution, Gamma,
White Balance, Exposure
Gain Fixed
Software
SFT-15003
rev 2.2.0.1 or above
• Videology viewer with active features
SFT-10011
rev 2.1.26 or above
• TWAIN Data Source
Recommended System Requirements
Hardware Requires USB 2.0 or USB 3 backwards compatible
UVC compliant ports
Operating Systems Windows XP, 7, 8, 10
Linux 2.6.26
Android 4.0 above (potential)
Mac OS 10.4.8 or above (potential)
Lens
3MP M-12 Board Mount Customized precision 12mm focal length with high
uniformity, MTF matched to sensor.
Depth of Field optimized for facial still image cap-
ture (4-8 feet range).
Mechanical preset selectors to extend this range
are in design for release by July, 2021
Environmental
Operating Temperature -15°C - 55°C (5°F-131°F)
Mechanical
Dimensions W x H x D 50mm x 100mm x 74mm (with fl ash and no lens)
Weight 154g
Included Cables 60C1138 - 2.5mm stereo (6” plug to plug)
60C1147 - USB 2.0 A to mini B cable (10ft)
Included Tripod Mount 1/4 20 mount for easy mounting capability
Compatible**
** under ideal conditions wrt face distance, lighting,
FOV, motion & software
Flash
Tripod Mount
Manual
fl ash dial
USB
100mm
50mm 74mm
10mm
To access appropriate focus be-
yond the recommended range of
4-8 feet, a 3 position wheel will be
added to the mechanicals.
Cables Included:
60C1138 2.5mm stereo (6” long)
60C1147 USB 2.0 A to mini B
cable (10ft. long)
Product Features
• Synchronized USB powered LED
fl ash for consistent high quality
images in any environment
• FHD progressive scan sensor for
1920 x 1080 still images
• Both Compressed (MJPEG) and Raw
video (YUY2) outputs supported. Still
image capture only with MJPEG
• USB 2.0 bus provides power, camera
and fl ash control
• UVC compliant
• Convenient manual dial allows
customized fl ash intensity
• 1/4 20 mount is on base for tripod use
• Full SDK available for integration into
customer applications - Check with
Sales
• TWAIN compatible
• NOTE: Neutral Gray backdrop is
recommended
Technical Specifi cations
24C708AF-1 REAL ID compatible
Full HD FLASH-SYNC for Facial Photo ID
Precision Pixel Matched Lensing
Larger Sensor Pixels
