All data subject to change without notice.

05/18/21 PDS-24C708AF-SYS-1 Rev B

Excellence.

Every day. Every time.

www.videologyinc.com

HEADQUARTERS LOCATION

Videology Industrial-Grade Cameras

35 Hampden Road

Mansfi eld, MA 02048 | United States

EUROPE LOCATION

Videology Industrial-Grade Cameras

High Tech Campus 5

5656 AE Eindhoven | The Netherlands

Software

SFT-15003

rev 2.2.0.1 or above

• Videology viewer with active features

SFT-10011

rev 2.1.26 or above

• TWAIN Data Source

Recommended System Requirements

HardwareRequires USB 2.0 or USB 3 backwards compatible

UVC compliant ports

Operating SystemsWindows XP, 7, 8, 10

Linux 2.6.26

Android 4.0 above (potential)

Mac OS 10.4.8 or above (potential)

Lens

3MP M-12 Board MountCustomized precision 12mm focal length with high

uniformity, MTF matched to sensor.

Depth of Field optimized for facial still image cap-

ture (4-8 feet range).

Mechanical preset selectors to extend this range

are in design for release by July, 2021

Environmental

Operating Temperature-15°C - 55°C (5°F-131°F)

Mechanical

Dimensions W x H x D131.4mm x 609.6mm x 122mm

(5.175” x 24” x 4.8”)

Weight1.587g (3.5lb)

Included Cables60C1138 - 2.5mm stereo (6” plug to plug)

60C1147 - USB 2.0 A to mini B cable (10ft)

Included Tripod Mount1/4 20 mount for easy mounting capability

24C708AF-SYS-1

Image Sensor Size1/2.7"

Pixel Size3m x 3mμμ

Resolution

and Frame

Rates

MJPEG

compressed

Still Capture choices1920x1080

(recommended)

1280 x 1024

1280x720

640x480

YUY2

uncompressed

Video Capture

choices. Still image

not possible

1920x1080/5fps

1280 x 1024/10fps

1280x720/20fps

640x480/30fps

Sensitivity0.1LUX/F2.0

Signal to Noise Ratio>65dB

Shutter ModeElectronic rolling shutter

Field of View (H x V)40° x 30°

Video OutputUSB 2.0

Power Supply5VDC via USB 2.0 bus

Power Consumption<200mA

UVC Controls

Still CaptureSelectable

FlashSelectable via Videology viewer or TWAIN

FocusManual

Preset for 4-8 feet

Image ControlsContrast, Brightness, Hue, Resolution, Gamma,

White Balance, Exposure

Gain Fixed

Compatible**

** under ideal conditions wrt face distance, lighting,

FOV, motion & software

Product Features

• Non-tilting stand

• Synchronized USB powered LED fl ash for consistent

high quality images in any environment

• FHD progressive scan sensor for 1920 x 1080 still images

• Both Compressed (MJPEG) and Raw video (YUY2) outputs

supported. Still image capture only with MJPEG

• USB 2.0 bus provides power, camera and flash control

• UVC compliant

• Convenient manual dial allows customized flash intensity

• 1/4 20 mount is on base for tripod use

• Full SDK available for integration into customer applica-

tions - Check with Sales

• TWAIN compatible

• NOTE: Neutral Gray backdrop is recommended

Technical Specifications

5.175”

131.4mm

21.5”

546.1mm

4.8”

122mm

24”

609.6mm

2.95”

75mm

7.25”

184.15mm

3.9”

100mm

12.8”

325.45mm

24C708AF-SYS-1REAL ID compatible

Full HD FLASH-SYNC for Facial

Photo ID System

Precision Pixel Matched Lensing

Larger Sensor Pixels
