VITEKCCTV.COM

(888) VITEK-70

VTD-TNMD4RFA3-2

4 MegaPixel Gen. III Advanced A.I. Indoor / Outdoor Fixed

IP Vandal Dome Camera [preliminary specs]

KEY FEATURES

• 1/3” 4.0 Megapixel Progressive Scan CMOS image sensor

• Up to 30fps live view @ 4 MegaPixel (2592x1520)

• Available with 2.8mm Fixed Iris Lens

• Supports Still Image Recording Function

• Matrix IR with up to 65’ IR Range

• 120dB Super Wide Dynamic Range (WDR)

• True Mechanical Day/Night function by ICR

• XD-DNR (2D-DNR & 3D-DNR) Noise Reduction

• Gen. III Advanced Analytics including Object Removal/Museum Search, Line

Crossing, and Area Intrusion Detection

• Smart H.265/H.265+/H.265/H.264/MJPEG Triple Streaming

• Remote Viewing via VMS, Internet Explorer, and iOS & Android Apps

• ONVIF Compliant

• MicroSD memory card slot for Local recording supporting up to 256GB

• IP66 Weather Resistance

• Built-In Microphone*

• 12VDC & PoE (Power over Ethernet) Operation

• 3 Year Warranty

VT-TWMT-3

Optional Wall

Mount

RECORDERS

Pair with VITEK Transcendent Series

Network Recorders VT-TNR818PF,

VT-TNR1646PF, and VT-TNR3216PF

with Built-in PoE and Advanced

Analytics including Face Detection.

SPECIFICATIONS

Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS

Image Size 4 MegaPixel (2592 × 1520)

Resolution 4MP (2592 × 1520) / 3MP (2304 × 1296) / 1080P (1920 ×

1080) / 720P (1280 × 720) / D1/CIF (480 × 240)

Min. Illumination

.005 [email protected], AGC on, 0 lux w/IR .0028 [email protected], AGC on; 0 lux w/IR

Lens 2.8mm Fixed Iris

Day/Night True Day/Night by ICR

IR LEDs 1 Matrix Style IR LED

IR Distance Up to 65’

Video Compression Smart H.265 / H.265+ / H.265 / Smart H.264 /

H.264+ / H.264 / MJPEG

Audio CompressionG.711A / G.711U

Main Stream4MP, 3MP, 1080P, 720P (60Hz: 1 ~ 30fps),

HFR mode: 1080P / 720P (60Hz: 1~60fps)

Sub, Third Stream

720P/D1/CIF/480×240(60Hz: ≤30fps), D1/CIF/480×240(60Hz: ≤ 30fps

Bit Rate64 Kbps ~ 8 Mbps

Wide Dynamic Range120dB Super WDR

Digital Noise Reduction 3D-DNR

Quality VBR (Five Levels of Adjustment) / CBR (Adjustable)

Other FeaturesDefog, Backlight Control, Highlight Control, M12 Lens Mount

Image Setting

ROI, Saturation, Brightness, Chroma, Contrast,

Sharpen, NR; adjustable through client

software or web browser

Gen. III Advanced Analytics

Abnormal Video, Face Detection, Regional Intrusion, Regional

Entrance / Exiting, Line Crossing, Target Counting

Smart Alarm Motion detection, SD card error, SD card full

Region of Interest (ROI) Each ROI to be configured separately

Audio 1 Ch. Audio In + Built in Mic*

Local StorageBuilt-in micro SD card slot up to 256GB

PoEYes , IEEE802.3af

Remote ViewingVMS / Web Browser / Mobile (iOS/Android)

Supported BrowsersInternet Explorer, Chrome and Firefox with IE Tab

Connection Protocol ONVIF

Resistance IP66

Power Input12VDC / PoE

Power Consumpt. (12VDC) 120mA (LEDs Off) / 480mA (LEDs On)

Power Consumpt. (PoE) < 6W

Working Environment -22° ~140° / < 95% Humidity

Weight .84lbs. / 380g

Dimensions4.33” × 2.35” (110mm × 59.8mm) Dia × H

*Please research local, state and federal laws regarding the implementation

of audio surveillance.

*Shown with optional wall

mount VT-TWMT-3

MOUNTS

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA

DIMENSIONS

5.10”

6.10”

2.93”
