Seite 1/17
05-05-2023 15:53
TVM 3840 Series
https://vogels.create-usermanual.com/en-us/tvm3840.html
1/17
Don’t dare risk it… Read all
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
…we just wanted to say thanks for choosing Vogel’s. Smart choice.
And you’re already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient
installation, and how to use your new mount.
Stay safe
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could put you, your TV, and
your family at substantial risk.
Vogel’s recommends that the mounting and/or installation of this product should be carried out by a suitably
qualified expert.
05-05-2023 15:53
TVM 3840 Series
https://vogels.create-usermanual.com/en-us/tvm3840.html
2/17
Vogel’s cannot be held responsible for any injury and/or damage caused by incorrect installation.
Please consult the manual for your TV and ensure that the weight and size of the TV is within the maximum weight
and size limits specified for this product, and that the TV mounting bolts used are of a suitable length and diameter.
Note that not all the TV mounting accessories provided are required for the installation of any one TV.
The wall mounting accessories provided are exclusively intended for installation on walls made of solid brick, solid
concrete or solid wood columns.
Any material covering the wall must not exceed 3 mm/ 0.12 inch.
For mounting on walls made of other materials, such as hollow bricks, wood panels or plasterboard, please consult
your installer and/or specialist supplier.
Clean the product with a dry, lint-free cloth. Do not use detergents or other solvents to clean the product.
Only qualified, certified personnel may repair the product. Use only original spare parts. The use of other parts will
result in voiding the warranty, and could lead to injuries.
Alterations to the product and technical modifications are not permitted. This will void the warranty, and could lead
to injuries.
Always store the product in a dry and safe place with a temperature between -10°C to +50°C.
Handle and transport the product with care.
Repack the product when transporting or not using it for a longer period of time.
Lifting your TV is a two-person job. Don’t be bold!
What’s in your box?
Something missing? Make sure your packaging has everything in place:
A. Wall mount
B. Interface bars
C. Interface strips
D. Safety instructions
E. Bolts for fastening strips on TV (see contents below)
F. Spacers
G. Washers Ø 18 mm
H. Screws
I. Plugs (fischer© DuoPower)
05-05-2023 15:53
TVM 3840 Series
https://vogels.create-usermanual.com/en-us/tvm3840.html
3/17
J. Washers Ø 26 mm
K. Covers
L. Protective TV patches
M. Cable clips
N. Spirit level
O. Interface bolts
P. Allen key
Contents of the TV fasteners kit:
4x M6*12mm bolts
4x M6*25mm bolts
4x M6*35mm bolts
4x M8*12mm bolts
4x M8*25mm bolts
4x M8*45mm bolts
4x M6 washer
4x spacer 10mm
4x spacer 5mm
You just need four bolts to mount your TV. Store the rest for other use!
Got your tools ready?
Don’t start without all the necessary tools:
Crosshead screwdriver
Drilling machine
10 mm or 25/64” concrete / brick drill (for concrete / brick walls only)
