INSTRUCTIONS Class II Plug-in Electronic Transformer

Model: EN-1260-P-AR

CAUTION – TO REDUCE RISK OF FIRE AND ELECTRICAL SHOCK

•Always turn o power at main switch prior to installation.

•For installation by a qualied electrician.

•System is intended for installation in accordance with National Electric Code, and local

regulations. Consult with local inspector to assure compliance.

MAX LOAD 60W

MIN LOAD 20W

INPUT VOLTAGE 120V

INPUT CURRENT 0.53A

OUTPUT VOLTAGE 11.6V

MAX CASE TEMP

75ºC (167F) °

AMBIENT TEMP

-20ºC TO 50ºC (-4F TO 122F) °°

FEATURES:

•Electronic short circuit protection with auto-reset.

•Overload protection with auto-reset.

•Automatic thermal protection.

•Soft start delay to preserve bulb life, for use with tungsten lament lamps.

•Convenient on/o switching ability.

•Includes 6’ detachable cord.

INSTALLATION:

Transformer plugs into standard 120 volt 3 prong grounded outlet.

Transformers must be installed away from heat sources.

Output wires may run direct to the xture leads, or longer (heavier gauge) wire maybe spliced in.

Class II output splices do not require enclosures.

Note: Transformer output is sucient to power a 60 watt load up to six feet away. It is

recommended to use not more than 40 watts load when longer wire runs are necessary.

MAXIMUM LENGTH / VOLTAGE DROP GUIDELINE

WIRE SIZE 35 WATT 50 WATT 60 WATT

18 GAUGE 10 FT 9 FT 8 FT

16 GAUGE 14 FT 13 FT 11 FT

14 GAUGE 21 FT 19 FT 15 FT

12 GAUGE 28 FT 25 FT 21 FT

Retain these instructions for future service and adjustments

615 South Street, Garden City, NY 11530

Tel: (516) 515-5000 Fax (516) 515-5050

www.waclighting.com
