Seite 1/5
Can be controlled/programmed remotely with a
smart device via the free ‘My Leviton’ app
Can be used with relay panels for load switching in
larger jobs or other voltages.
Works with Amazon’s Alexa, Google Assistant, SmartThings,
Nest, Ring and IFTTT (no automation hub required)
Terminal block for easy wiring
Wall-mount enclosure with hinged cover
May be used for snow melting or roof and
gutter deicing systems
Can also be operated manually
Front door easy-lock clasp operates using
a coin or large screwdriver
Switches up to 15 AMPS with 120 VAC (operational voltage) Mounts in indoor nonhazardous locations
Features and Benefits
Description
Installation Manual
SCW-120-15A
Snow and Ice Melting
Wifi Control
The WarmlyYours SCW-120-15A Snow and Ice Melting WiFi Control is a flexible, user-friendly, and,
aordable option for snow melting and roof and gutter deicing systems. This unit features a built-in 120V
WiFi standard switch and can be used with a compatible relay panel. The relay panel, sold separately,
can help switch voltages ranging from 120V to 277V. This unit can switch up to 15 AMPS with 120V,
eliminating the need for a relay panel for small jobs.
Installation Support • (800) 875-5285 • www.WarmlyYours.com
Front Side
GND
H
N
N
GND
H
N
RH
N
Heating
Element
(120V,
15 Amps
Max)
GROUND
HOT
NEUTRAL
Wifi
WHITE
RED
RED
BLACK
BLACK
GRD
GRD
GND
H
NN
RH
1 2 3 4 5
120V Supply
WHITE
Wiring Scheme Inside Panel
Specifications
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . .6.375” (162mm) wide x 6.375” (162mm) high x 4” (102mm) deep
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.0 lbs (2.3kg)
*Shipping weight may vary
Ordering Information
Order Number Description . . . . . . . . . . . .SCW-120-15A Snow and Ice Melting WiFi Control
Limited Warranty
WarmlyYours 2-year limited warranty covering defects in workmanship and materials applies.
Contact your Account Manager for complete warranty information.
This document is the property of WarmlyYours. Subject to change without notice.
Installation Support • (800) 875-5285 • www.WarmlyYours.com
SCW-120-15A
Snow and Ice Melting Wifi Control
to Heating Element
Installation Manual
Specifications
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . .6.375” (162mm) wide x 6.375” (162mm) high x 4” (102mm) deep
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.0 lbs (2.3kg)
*Shipping weight may vary
Ordering Information
Order Number Description . . . . . . . . . . . .SCW-120-15A Snow and Ice Melting WiFi Control
Limited Warranty
WarmlyYours 2-year limited warranty covering defects in workmanship and materials applies.
Contact your Account Manager for complete warranty information.
This document is the property of WarmlyYours. Subject to change without notice.
Installation Support • (800) 875-5285 • www.WarmlyYours.com
GND
H
N
N
GND
H
N
RH
N
GROUND
HOT
NEUTRAL
Wifi
WHITE
RED
RED
BLACK
BLACK
GRD
GRD
GND
H
NN
RH
1 2 3 4 5
120V Supply
WHITE
OUTPUT TO RELAY
Hot Wire Goes to
Rh Red Terminal
Neutral Wire Goes to
White Terminal
OUT
SCW-120-15A
Snow and Ice Melting Wifi Control
to Relay Panel
Installation Manual
Wiring Scheme Inside Panel
