THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your product on www.whirlpool.eu/register
Policies, standard documentation, ordering of spare parts and additional product information can be
found by:
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product’s identication plate.
EN
Quick guide
Before using the appliance carefully read the Safety
Instruction.
xxxxxxxxxxxx
xxxx
OPENING OF THE DOOR DURING THE CYCLE
Laundry can be checked while the drying cycle runs and any
garments already dry can be removed, while drying continues for
the remaining items. After closing the door, press the "Start/Pause"
button to resume machine operation.
Keep the door closed until the cycle end to save time and energy.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying cycle.
- remember to clean your lters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door lter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items.
3. Close the door.
4. Press the "On/O" button.
5. Select the most suitable programme
for the type of fabric in that
load.
6. Select the options, if necessary.
7. Press the "
Start/Pause"
button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Pull the load out
immediately to prevent the formation of creases on laundry.
9. Turn the machine o by pressing the "On/O" button, open the
door and pull the clothing out. If the machine is not switched o
manually, after about a quarter of an hour from the end of the
cycle , the appliance turns o automatically to save energy.
Note that some programme/option accords with "Crease Care"
system. This means that for some hours, after the end of the
drying cycle, the drum rotates at regular intervals to prevent the
formation of creases.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is xed correctly,
either to the dryer’s water tank, or to your domestic drainage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
CONTROL PANEL
1 ON/OFF button (hold for Reset)
2 Programme selection Knob
3 Start/Pause
Options buttons*
4 Dryness level
5 Start delay
6 Timed drying
7 Cycle end
8 Rapid (hold for Key lock)
9 FreshCare+ (hold for Mute)
*Note: some models may have the wording in full instead of the icons.
INDICATORS
Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry
Cycle phase:
Drying - Cool down - End of cycle.
Empty water tank- Clean door lter - Clean bottom lter -
Refer to troubleshooting section:
Failure: Call after sales service -
DEMO
Demo mode
1
3
2
9
7
8
456
3’’
3’’
h
1
3
2
9
7
8
456
h
3’’
3’’
Produktspezifikationen
| Marke: | Whirlpool |
| Kategorie: | Trockner |
| Modell: | FFT M11 72B EE |
| Breite: | 595 mm |
| Tiefe: | 649 mm |
| Gewicht: | 46500 g |
| Produktfarbe: | Weiß |
| Steuerung: | Buttons, Rotary |
| Höhe: | 849 mm |
| Eingebautes Display: | Ja |
| Geräteplatzierung: | Freistehend |
| Kabellänge: | 1.5 m |
| Energieeffizienzskala: | A+++ bis D |
| Trockenprogramme: | Baby care, Bedding, Delicate/silk, Iron dry, Jeans/denim, Lingerie, Mix, Quick, Sport, Synthetics |
| Startzeitvorwahl: | Ja |
| Verstellbare Füße: | Ja |
| Ladetyp: | Frontlader |
| Anschlusswert: | 850 W |
| Stromstärke: | 10 A |
| Jährlicher Energieverbrauch: | 211 kWh |
| Wärmequelle: | Elektro |
| Zykluszeit: | 180 min |
| Nennkapazität: | 7 kg |
| Geräuschpegel: | 65 dB |
| Türanschlag: | Rechts |
| Türfarbe: | Schwarz |
| Tiefe bei geöffneter Tür: | 1092 mm |
| Einschalteverzögerung (max.): | 24 h |
| Kindersicherung: | Ja |
| Restzeitanzeige: | Ja |
| Ein-/Ausschalter: | Ja |
| Alarm: | Ja |
| Trommelvolumen: | 120 l |
| Feuchtigkeitssensor: | Ja |
| Einfache Bügelfunktion: | Ja |
| Betriebsbereitschaftsanzeige: | Ja |
| Türstil: | Glastür |
| Anzeige Wassertank voll: | Ja |
| Umgekehrter Trommelbetrieb: | Ja |
| Whirlpool-Technologien (Kleiderpflege): | FreshCare+ |
