Whirlpool W7 D93SB EE Bedienungsanleitung
Seiten 72 Trockner
Lies die Bedienungsanleitung für Whirlpool W7 D93SB EE kostenlos online oder lade das PDF herunter. 23 Personen fanden diese Anleitung hilfreich. Frage zu diesem Modell? Stelle eine Frage
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your product on www.whirlpool.eu/register
Policies, standard documentation, ordering of spare parts and additional product information can be
found by:
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product’s identification plate.
EN
Quick guide
Before using the appliance carefully read the Safety
Instruction.
xxxxxxxxxxxx
xxxx
Eco Monitor
This indicator shows the energy consumption level according to
the programme and the options set. The consumption is
proportional to the lines on the display, by the ecomonitor icon.
OPENING THE DOOR DURING THE CYCLE
Laundry can be checked while the drying cycle runs and any
garments already dry can be removed, while drying continues for
the remaining items. After closing the door, press the "Start/Pause"
button to resume machine operation.
Keep the door closed until the cycle end to save time and energy.
NAVIGATION
The "UP" and "DOWN" buttons are used to navigate the available
menus.
•Press the button to confirm the selection.
•Press the option button at the symbol, where present on the
display, to return to the previous screen.
If no selection is conrmed, after about 10 seconds, the display
return to the main screen.
SETTINGS
To access the Settings menu, press and hold the relevant button for a
few seconds.
•Set language shows the available languages on the display.
•Sounds allows to enable or disable the sounds (some sounds, as
warnings, will remain active anyway).
•Brightness allows to modify the display brightness.
•Factory Default allows to reset the default settings. After having
selected the setting, press and hold the button for a few
seconds.
FIRST TIME USE
When starting the appliance the first time, the control panel will
automatically show the set language menu. The UP and DOWN
buttons are used to show the languages available in the
machine. Press the buttonto confirm. The machine cannot be
used without having selected the language.
Make sure that the water tank is correctly inserted.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before using the dryer make sure it has been in an upright
position for at least 6 hours.
Should you wish to change the opening side of the door, please
contact our After-sales Service. (See phone number in the
warranty booklet).
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying cycle.
- remember to clean your lters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door filter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items.
3. Close the door.
4. Press the "On/Off" button.
5. Select the most suitable programme
for the type of fabric in that
load.
6. Select the options, if necessary.
7. Press the "
Start/Pause"
button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Pull the load out
immediately to prevent the formation of creases on laundry.
9. Turn the machine off by pressing the "On/Off" button, open the
door and pull the clothing out. If the machine is not switched off
manually, after about a quarter of an hour from the end of the
cycle , the appliance turns off automatically to save energy.
Note that some programme/option accords with "Crease Care"
system. This means that for some hours, after the end of the
drying cycle, the drum rotates at regular intervals to prevent the
formation of creases.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
INDICATORS
Cycle phase: Drying - Cool Down
Empty water tank- Clean secondary lter - Clogged door lters - Autoclean - Eco Monitor
Refer to Troubleshooting section:
Failure call After-sales Service -
DEMO
Demo Mode
CONTROL PANEL
1 Programme selection knob
2 On/Off button
3 Start/Pause button
Options buttons
4 FreshCare+
5 Cycle End Signal
6 Rapid
7 Cycle Options (hold for Settings)
8 Dryness Level
9 Timed Drying
10 Start Delay
Navigation buttons and Key Lock
11 UP
12 DOWN
13 CONFIRM (hold for Key Lock)
1
SYNTHETICS
1:35
-:--
-:--
5
6
7
11
12
13
2
3
4
8910
Produktspezifikationen
| Marke: | Whirlpool |
| Kategorie: | Trockner |
| Modell: | W7 D93SB EE |
| Display-Typ: | LCD |
| Nahfeldkommunikation (NFC): | Nein |
| Breite: | 597 mm |
| Tiefe: | 656 mm |
| Gewicht: | 50500 g |
| Produktfarbe: | Silber |
| Steuerung: | Buttons, Rotary |
| Höhe: | 849 mm |
| AC Eingangsspannung: | 220 - 240 V |
| AC Eingangsfrequenz: | 50 Hz |
| Eingebautes Display: | Ja |
| Verpackungsbreite: | 655 mm |
| Verpackungstiefe: | 684 mm |
| Verpackungshöhe: | 874 mm |
| Paketgewicht: | 52000 g |
| Geräteplatzierung: | Freistehend |
| Kabellänge: | 1.5 m |
| Stromverbrauch (Standby): | 2 W |
| Energieeffizienzskala: | A++ bis D |
| Trockenprogramme: | Blanket, Eco, Jeans/denim, Mix, Sport, Synthetics |
| Startzeitvorwahl: | Ja |
| Verstellbare Füße: | Ja |
| Ladetyp: | Frontlader |
| Stromstärke: | 10 A |
| Jährlicher Energieverbrauch: | 259 kWh |
| Wärmequelle: | Elektro |
| Energieverbrauch: | 2.12 kWh |
| Zykluszeit: | 250 min |
| Nennkapazität: | 9 kg |
| Geräuschpegel: | 59 dB |
| Trommelmaterial: | Edelstahl |
| Wechselbare Türen: | Nein |
| Türfarbe: | Schwarz |
| Trocknungssystem: | Wärmepumpe |
| Restzeitanzeige: | Ja |
| Invertertechnologie: | Ja |
| Stromverbrauch (aus): | 0.5 W |
| Türöffnungswinkel: | 130 ° |
| Trommelvolumen: | 120 l |
| Wi-Fi-gesteuert: | Nein |
| Anzahl Trocknungsprogramme: | 15 |
| Filtereinigungsindikator: | Ja |
| Anzeige Wassertank voll: | Ja |
