ENDaily Reference Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

1. ON-OFF/Reset button

with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE program button with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Key lock indicator light

10. Program number remaining time and indicator

11. Display

12. Power Clean® option button with indicator light

FIRST TIME USE

1 2 3 4 11 12 13 14 155 6 7 8 9 10 16

13. Half Load option Settings button with indicator light/ - 3 sec. press

14. Extra Dry Option button with indicator light - 3 sec. press/ Keylock

15. Delay option button with indicator light

16. START/Pause button with indicator light

Before using the appliance carefully read

Safety and Installation Instructions. More information about your

product available on website: docs.whirlpool.eu

After installation, please remember to remove all transport protection

parts from the dishwasher.

SETTING MENU

1. Switch on the appliance by pressing the button.ON-OFF

2. Hold the Settings (Half Load ) button for 3 seconds, until you hear

a beep and the display shows „SEt”.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press PREVIOUS /NEXT to scroll through the list of available settings

(see table below), then press START/Pause to view and change the

value of the currently selected setting.

5. Press PREVIOUS /NEXT to change the value, then press START/Pause

to save the new value and return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press or wait 30 seconds to exit the menu.ON-OFF

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the con-

trol panel is lit.1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 0,5 kg); it is not un-

usual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Run a program every time as soon as you completed relling the salt

reservoir to avoid corrosion.

Setting the water hardness

To allow the water softener to work in a perfect way, it is essential that the water

hardness setting is based on the actual water hardness in your house. This infor-

mation can be obtained from your local water supplier. The factory setting is “3”.

See „WATER HARDNESS TABLE”.

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Use of salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better clean-

ing eciency. This system regenerates itself with salt, therefore it is

required to rell the salt container when empty. The frequency of re-

generation depends on the water hardness level setting - regeneration

takes place once per Eco cycles with the water hardness level set to 4-6 3.

The regeneration process occurs at the beginning of the cycle with addi-

tional fresh water.

• Single regeneration consumes: ~3L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser should be A

lled when the RINSE AID REFILL indicator light in the control panel is lit.

1. Open the dispenser B by

pressing and pulling up the

tab on the lid.

2. Pour in the rinse aid (max.110

ml), making sure it does not

overow from the dispenser.

If this happens, clean the spill

immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub..

Adjusting the dosage of rinse aid

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of levels can be set according to the dishwasher model. 6

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set

a mid-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce

the detergent into the dry dispenser D only. Place the amount of

detergent for pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser there are indicaD, -

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the

dispenser and close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling

it up until the closing device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

LETTER SETTING VALUES

(Default - )in bold

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”) 1 | 2 | | 4 | 53

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”) 0 | 1 | 2 | 3 | 4 | 5

NaturalDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O 1 | 0

Sound

“1” = On, “0” = O 1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included in

the settings menu.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (soft) 0 - 6 0 - 10 0 - 7

2 (medium) 7 - 11 11 - 20 8 - 14

3 (average) 12 - 16 21 - 29 15 - 20

4 (hard) 17 - 34 30 - 60 21 - 42

5 (very hard) 35 - 50 61 - 90 43 - 62

CONTROL PANEL

1. CHECK WATER CONNECTION

Check that the dishwasher is connected to the water supply and that

the tap is open.

2. SWITCH ON THE DISHWASHER

Press the button.ON/OFF

3. LOAD THE RACKS (see LOADING THE RACKS).

4. FILL THE DETERGENT DISPENSER

5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE

Select the most appropriate program in accordance with the type of

crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing

the PREVIOUS/NEXT buttons.

Select the desired options . Not all (see OPTIONS AND FUNCTIONS)

options are compatible with all programs.

6. START

Start the wash cycle by closing the door and pressing START/Pause

button (led is lit). When the program starts you hear a single beep.

7. END OF WASH CYCLE

The end of the wash cycle is indicated by sound and the display shows

END. Switch o the appliance by pressing the button and ON/OFF

opening the door.

Wait for a few minutes before removing the crockery - to avoid burns.

Unload the racks, beginning with the lower one.

MODIFYING A RUNNING PROGRAM

If a wrong program was selected, it is possible to change it, provided that

it has only just begun. the machine: press and hold theRESET ON/OFF

button for more than 3. sec., and the machine will switch o. The dashboard

will show “0:01”. Wait until drain cycle ends (around 1 minute). Switch the

machine back on using the button and select the new wash cycle ON/OFF

and any desired options. Start the cycle by pressing the START/Pause button.

ADDING EXTRA CROCKERY

Without switching o the machine, open the door rst slightly to avoid wa-

ter splashing out (START/Pause Caution!: Hot steam! led starts blinking) ( )

and place the crockery inside the dishwasher. Close the door and press the

START/Pause button, the cycle will resume from the point at which it was

interrupted.

ACCIDENTAL INTERRUPTIONS

If the door is opened during the wash cycle, or if there is a power cut, the

cycle stops. Close the door and ONLY IF YOU PRESS START/Pause the

button the cycle will resume from the point at which it was interrupted.

TIPS

Before loading the baskets, remove all food residues from the crockery

and

empty the glasses. You do not need to rinse beforehand under running

water.

Arrange the crockery so that it is held in place rmly and does not tip over;

and arrange the containers with the openings facing downwards and the

concave/convex parts placed obliquely, thus allowing the water to reach

every surface and ow freely.

Warning: lids, handles, trays and frying pans should not prevent the

sprayer arms from rotating.

Place any small items in the cutlery basket.

Very soiled dishes and pans should be placed in the lower basket because

in this sector the water sprays are stronger and allow a higher washing

performance.

After loading the appliance, make sure that the sprayer arms can rotate

freely.

UNSUITABLE CROCKERY

• Wooden crockery and cutlery.

• Delicately decorated glasses, artistic handicrafts and antique crockery.

Their decorations are not resistant.

• Parts in synthetic material which do not withstand high temperatures.

• Copper and tin crockery.

• Crockery soiled with ash, wax, lubricating grease or ink.

The colours of glass decorations and aluminium/silver pieces can change

and fade during the washing process. Some types of glass (e.g. crystal

objects) can become opaque after a number of wash cycles too.

DAMAGE TO GLASS AND CROCKERY

• Only use glasses and porcelain guaranteed by the manufacturer as

dishwasher safe.

• Use a delicate detergent suitable for crockery

• Collect glasses and cutlery from the dishwasher as soon as the wash

cycle is over.

TIPS ON ENERGY SAVING

• When the household dishwasher is used according to the manufactur-

er’s instructions, washing tableware in a dishwasher usually con-

sumes less energy and water than hand dishwashing.

• In order to maximize dishwasher eciency, it is recommended to

initiate the wash cycle once the dishwasher is fully loaded. Loading

the household dishwasher up to the capacity indicated by the manu-

facturer will contribute to energy and water savings. Information on the

correct loading of tableware can be found in the Loading chapter.

In case of partial loading, it is recommended to use a dedicated wash op-

tions if available (Half load/ Zone Wash/ Multizone), lling up only select-

ed racks. Incorrect loading or overloading of the dishwasher may increase

resources usage (such as water, energy and time, as well as increase noise

level), reducing cleaning and drying performance.

• Manual pre-rinsing of tableware items leads to increased water and

energy consumption and is not recommended.

HYGIENE

To avoid odour and sediment which can be accumulated in the dishwash-

er please run a high-temperature program at least once a month.

Use a teaspoon of detergent and run it without loading to clean your

appliance.

RESISTANCE TO FROST

If the appliance is placed in surroundings exposed to the risk of frost, it

must be drained completely. Turn o the water tap, remove the inlet and

outlet hoses, and let all the water drain away. Make sure that the water

softener is full of dissolved regeneration salt in the salt container, to

protect the appliance from temperatures of up to -20°C.

If the appliance was stored in frost conditions the appliance must remain at

an ambient temperature of min. 5°C for before the rst run.at least 24 hours

ADVICE AND TIPS

DAILY USE

ENDaily Reference Guide

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and pressure of the incoming

water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor calibration. The sensor calibration can increase

program duration by up to 20 min.

PROGRAMS TABLE

Program Programs description

Drying

phase

NaturalDry

Available

options *)

Duration

of wash

program

(h:min)**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco - Program is suitable to clean normally soiled tableware, 50°

that for this use, it is the most ecient program in terms of its

combined energy and water consumption, and that it is used to

assess compliance with the EU Ecodesign legislation. 3:30 9.5 0.76

P2 Auto Intensive 65° - Automatic pro-

gram for heavily soiled dishes and pans. Senses the level of

soiling on the dishes

and adjusts the program

accordingly. When the

sensor is detecting the

soil level an animation

appears in the display

and the cycle duration is

updated.

2:25 - 3:10 15.5 - 24.5 1.30 - 1.70

Auto Mixed - 55° Automatic program

for normally soiled dishes with dried

food residues. 1:20 - 3:00 7.5 - 19.5 0.75 - 1.20

Auto Fast 50° - Automatic program

for normally and lightly soiled dishes.

The everyday cycle that ensures optimal

cleaning and drying performance in a

shorter time.

1:00 - 1:50 0.70 - 1.107.5 - 15.5

Rapid 45°

- Program is recommended for limited amount of

lightly-soiled dishes with no dried food residues. Does not include

the drying phase.

- 0:30 - 0:40 0.55 - 0.6510.0 - 12.0

Crystals 45° - Program for delicate items, which are more sensitive

to high temperatures, for example, glasses and cups.

1:40 - 1:50 12.5 - 16.5 0.95 - 1.20

Silent - 55° Suitable for night-time operation of the appliance.

Ensures optimal cleaning and drying performance with the

lowest noise emission. 3:50 - 4:10 10.5 - 14.5 0.80 - 1.15

Sanitizing 65° - Normally or heavily soiled crockery, with

additional antibacterial wash. Can be used to perform

maintenance of the dishwasher. - 1:55 - 2:10 12.0 - 19.0 1.40 - 1.80

P9 Prewash - Used to refresh crockery planned to be washed later.

No detergent is to be used with this program. - 0:12 4.5 0.10

P10

Self Clean 65° - Program to be used to perform maintenance

of the dishwasher, to be carried out only when the dishwasher

is EMPTY using specic detergents designed for dishwasher

maintenance.

-- 1:15 11.0 1.10

FAVOURITE  The FAVOURITE program may be saved and will be easily

accessible. Find the program using / , and then press the PREVIOUS NEXT

FAVOURITE program button for 3 seconds..

DESCALE – Alarm - Limescale accumulation was detected on the internal

components of the appliance. Check if the Water Hardness Setting is

at the correct value and salt is present in the salt container (see FIRST TIME

USE), then use a descaling product (WPro brand is recommended) with the

Self-Clean program. After a successful descaling, the icon will stop being

displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and « » alarm will appear on the dES

display. If still no action is taken, the appliance will only allow a certain number

of cycles to be started (indicated during « » alarm display) and then will dES

be BLOCKED to prevent component damage, with only the Self-Clean

program available. Performing a full descaling will unblock the product.

In the case of extremely high amounts of limescale, descaling may have to

be performed twice to be ecient.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(please refer to the Power Clean in loading section).®

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected program.

Remember to reduce the amount of detergent.

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allows for improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between and hours.0:30 24

1. Select the program and any desired options. Press the DELAY button

(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24

hours. Once the 24 hours setting is reached, press the DELAY another time

to deactivate the DELAY function.

2. Close the door and press the START/Pause button. The timer will begin

counting down.

3. Once this time has elapsed, the indicator light switches o and the

program begins automatically.

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

NaturalDry - It is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying per-

formance every day. The door opens at a temperature that is safe to your

kitchen furniture.

As additional steam protection, specially designed protection foil is added

together with the dishwasher.

To see how to mount protection foil please refer to the INSTALLATION GUIDE.

This feature is active by default, but it is possible to deactivate it in the

“SETTINGS MENU”.

OPTIONS AND FUNCTIONS

SENSING - When the sensor is detecting the soil level an

animation appears in the display (around 20 min.) and the cycle

duration is updated. SENSING is for the level of soiling on the dishes and it

is present for all cycles (excepting Eco) adjusting the program accordingly.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL) (see PROGRAMS TABLE). If an option is not compatible with the selected program , the corresponding LED ashes rapidly

3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

KEYLOCK - A long press (for 3 seconds) of EXTRA DRY button, will

activate the KEYLOCK function. The KEYLOCK function will block the control

panel except for the ON/OFF button. To deactivate the KEYLOCK, long press

again

Produktspezifikationen

Marke:	Whirlpool
Kategorie:	Spülmaschine
Modell:	W7F HP43 X

Brauchst du Hilfe?

Wenn Sie Hilfe mit Whirlpool W7F HP43 X benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Spülmaschine Whirlpool

Whirlpool ADG 522 IX Bedienungsanleitung

12 Oktober 2024

Whirlpool WFC 3C26 P IS Bedienungsanleitung

9 Oktober 2024

Whirlpool WRIC 3C26 Bedienungsanleitung

7 Oktober 2024

Whirlpool WFC 3C33 PF UK Bedienungsanleitung

7 Oktober 2024

Whirlpool DU5000XL0 Bedienungsanleitung

7 Oktober 2024

Whirlpool ADG 4820 Bedienungsanleitung

5 Oktober 2024

Whirlpool WFO 3O32 P UK Bedienungsanleitung

23 September 2024

Whirlpool WDF130PAHS Bedienungsanleitung

23 September 2024

Whirlpool ADG 8516/1 Bedienungsanleitung

20 September 2024

Whirlpool ADG 8732 NB Bedienungsanleitung

18 September 2024

Bedienungsanleitung Spülmaschine

Neueste Bedienungsanleitung für -Kategorien-

Siemens 15 Bedienungsanleitung

12 Dezember 2023

Exquisit EGSP130-E Bedienungsanleitung

11 Mai 2024

BEKO BDFN26530B Bedienungsanleitung

4 Dezember 2024

BEKO BDEN38560CHPA Bedienungsanleitung

4 Dezember 2024

BEKO BDIN16520Q Bedienungsanleitung

4 Dezember 2024

BEKO BDFN15421W Bedienungsanleitung

4 Dezember 2024

BEKO BDIN15320 Bedienungsanleitung

4 Dezember 2024

BEKO BDFS15020B Bedienungsanleitung

4 Dezember 2024

BEKO BDFS15020S Bedienungsanleitung

4 Dezember 2024

BEKO BDFN15421S Bedienungsanleitung

4 Dezember 2024
