SAFETY

INSTRUCTIONS

ALWAYS WEAR EYE, FACE

AND EAR PROTECTION

When operating the tool

Electrical safety

Using an extension lead

Description of symbols

Circular Saw Safety

Warnings

XCS-185U 0516

Keep the mains cable away from any moving parts or

accessories.

Never cover the ventilation slots in the tool.

General Power Tool Safety

Warnings

WARNING! Read all safety

warnings and all instructions. Failure

to follow the warnings and instructions may

result in electric shock, re and/or serious

injury.

Save all warnings and instructions

for future reference. The term “power

tool” in all of the warnings refers to your

mains-operated (corded) power tool or battery-

operated (cordless) power tool.

Read instruction manual

Before you connect the charger to the mains supply

make sure that the data on the rating plate are identical

to the mains data.

Always use an approved extension lead suitable for

the power input of this tool. Before use, inspect the

extension lead for signs of damage, wear and ageing.

Replace the extension lead if damaged or defective.

When using an extension lead on a reel, always

unwind the lead completely. Use of an extension lead

not suitable for the power input of the tool or which is

damaged or defective may result in a risk of re and

electric shock.

The power supply for this product should be protected

by a residual current device (rated at 30mA or less).

A residual current device reduces the risk of electric

shock.

If the supply cord is damaged, it must be replaced

by the manufacturer, its service agent or similarly

qualied persons in order to avoid a hazard.

This tool is double insulated, therefore no earth

wire is required.

1) Work area safety

a) Keep work area clean and well lit.

Cluttered and dark areas invite accidents.

b) Do not operate power tools in

explosive atmospheres, such as in the

presence of ammable liquids, gases or

dust.

Power tools create sparks which may ignite the dust

or fumes.

c) Keep children and bystanders away

while operating a power tool. Distractions can

cause you to lose control.

2) Electrical safety

a) Power tool plugs must match the

outlet. Never modify the plug in any

way. Do not use any adapter plugs with

earthed (grounded) power tools. Unmodied

plugs and matching outlets will reduce risk of electric

shock.

b) Avoid body contact with earthed

or grounded surfaces such as pipes,

radiators, ranges and refrigerators. There

is an increased risk of electric shock if your body is

earthed or grounded.

c) Do not expose power tools to rain or

wet conditions. Water entering a power tool will

increase the risk of electric shock.

d) Do not abuse the cord. Never use the

cord for carrying, pulling or unplugging

the power tool. Keep cord away from

heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase the risk of

electric shock.

e) When operating a power tool outdoors,

use an extension cord suitable for

outdoor use. Use of a cord suitable for outdoor

use reduces the risk of electric shock.

f) If operating a power tool in a damp

location is unavoidable, use a residual

current device (RCD) protected supply.

Use of an RCD reduces the risk of electric shock.

3) Personal safety

a) Stay alert, watch what you are doing

and use common sense when operating a

power tool. Do not use a power tool while

drugs, alcohol or medication. A moment of

inattention while operating power tools may result in

serious personal injury.

b) Use personal protective equipment.

Always wear eye protection. Personal

protective equipment such as dust mask, non-skid

safety shoes, hard hat, or hearing protection used for

appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure

the switch is in the off-position before

connecting to power source and/or

battery pack, picking up or carrying the

tool. Carrying power tools with your nger on the

switch or energising power tools that have the switch

on invites accidents.

d) Remove any adjusting key or wrench

before turning the power tool on. A wrench

or a key left attached to a rotating part of the power

tool may result in personal injury.

e) Do not overreach. Keep proper footing

and balance at all times. This enables better

control of the power tool in unexpected situations.

f) Dress properly. Do not wear loose

clothing or jewellery. Keep your hair,

clothing and gloves away from moving

parts. Loose clothes, jewellery or long hair can be

caught in moving parts.

g) If devices are provided for the

connection of dust extraction and

collection facilities, ensure these are

connected and properly used. Use of dust

collection can reduce dust-related hazards.

4) Power tool use and care

a) Do not force the power tool. Use the

correct power tool for your application.

The correct power tool will do the job better and safer

at the rate for which it was designed.

b) Do not use the power tool if the switch

does not turn it on and off. Any power tool

that cannot be controlled with the switch is dangerous

and must be repaired.

c) Disconnect the plug from the power

source and/or the battery pack from

the power tool before making any

adjustments, changing accessories, or

storing power tools. Such preventive safety

measures reduce the risk of starting the power tool

accidentally.

d) Store idle power tools out of the reach

of children and do not allow persons

unfamiliar with the power tool or these

instructions to operate the power tool.

Power tools are dangerous in the hands of untrained

users.

e) Maintain power tools. Check for

misalignment or binding of moving parts,

breakage of parts and any other condition

that may affect the power tools operation.

If damaged, have the power tool repaired

before use. Many accidents are caused by poorly

maintained power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp cutting

edges are less likely to bind and are easier to control.

g) Use the power tool, accessories

and tool bits etc. in accordance with

these instructions and in the manner

intended for the particular type of power

tool, taking into account the working

conditions and the work to be performed.

Use of the power tool for operations different from

those intended could result in a hazardous situation.

5) Service

a) Have your power tool serviced by

a qualied repair person using only

identical replacement parts. This will ensure

that the safety of the power tool is maintained.

Original Instructions

XCS

-

185U

185mm

Circular

Saw

WARNING!

a) Keep hands away from cutting area

and the blade. Keep your second hand on

auxiliary handle, or motor housing. If both

hands are holding the saw, they cannot be

cut by the blade.

b) Do not reach underneath the

workpiece. The guard cannot protect you

from the blade below the workpiece.

c) Adjust the cutting depth to the

thickness of the workpiece. Less than a

full tooth of the blade teeth should be visible

below the workpiece.

d) Never hold piece being cut in your

hands or across your leg. Secure the

workpiece to a stable platform. It is

important to support the work properly to

minimize body exposure, blade binding, or

loss of control.

e) Hold power tool by insulated gripping

surfaces when performing an operation

where the cutting tool may contact

hidden wiring or its own cord. Contact

with a “live” wire will also make exposed

metal parts of the power tool “live” and shock

the operator.

f) When ripping always use a rip fence

or straight edge guide. This improves the

accuracy of cut and reduces the chance of

blade binding.

g) Always use blades with correct size

and shape (diamond versus round) of

arbour holes. Blades that do not match

the mounting hardware of the saw will run

eccentrically, causing loss of control.

h) Never use damaged or incorrect blade

washers or bolt. The blade washers and

bolt were specially designed for your saw,

for optimum performance and safety of

operation.

Further safety instructions for all saws

Causes and operator prevention of

kickback:

• Kickback is a sudden reaction to a pinched,

bound or misaligned saw blade, causing

an uncontrolled saw to lift up and out of the

workpiece toward the operator;

• When the blade is pinched or bound tightly

by the kerf closing down, the blade stalls

and the motor reaction drives the unit rapidly

back toward the operator;

• If the blade becomes twisted or misaligned

in the cut, the teeth at the back edge of the

blade can dig into the top surface of the

wood causing the blade to climb out of the

kerf and jump back toward the operator.

Kickback is the result of saw misuse and/or

incorrect operating procedures or conditions

and can be avoided by taking proper

precautions as given below.

a) Maintain a rm grip with both hands on

the saw and position your arms to resist

kickback forces. Position your body to

either side of the blade, but not in line

with the blade. Kickback could cause the

saw to jump backwards, but kickback forces

can be controlled by the operator, if proper

precautions are taken.

21

b) When blade is binding, or when

interrupting a cut for any reason, release

the trigger and hold the saw motionless

in the material until the blade comes to a

complete stop. Never attempt to remove

the saw from the work or pull the saw

backward while the blade is in motion or

kickback may occur. Investigate and take

corrective actions to eliminate the cause of

blade binding.

c) When restarting a saw in the

workpiece, centre the saw blade in the

kerf and check that saw teeth are not

engaged into the material. If saw blade is

binding, it may walk up or kickback from the

workpiece as the saw is restarted.

d) Support large panels to minimise the

risk of blade pinching and kickback.

Large panels tend to sag under their own

weight. Supports must be placed under the

panel on both sides, near the line of cut and

near the edge of the panel.

e) Do not use dull or damaged blades.

Blunt or improperly set blades produce

narrow kerf causing excessive friction, blade

binding and kickback.

f) Blade depth and bevel adjusting

locking levers must be tight and secure

before making cut. If blade adjustment

shifts while cutting, it may cause

binding and kickback.

g) Use extra caution when making a

“plunge cut” into existing walls or other

blind areas. The protruding blade may cut

objects that can cause kickback.

h) Check lower guard for proper closing

before each use. Do not operate the saw

if lower guard does not move freely and

close instantly. Never clamp or tie the

lower guard into the open position. If

saw is accidentally dropped, lower guard

may be bent. Raise the lower guard with the

retracting handle and make sure it moves

freely and does not touch the blade or any

other part, in all angles and depths of cut.

i) Check the operation of the lower guard

spring. If the guard and the spring are not

operating properly, they must be serviced

before use. The lower guard may become

sluggish due to, gummy deposits, or a build-

up of debris.

j) Lower guard may be retracted manually

only for special cuts such as “plunge

cuts” and “compound cuts.” Raise lower

guard by retracting handle and as soon

as blade enters the material, the lower

guard must be released. For all other

sawing, the lower guard should operate

automatically.

k) Always observe that the lower guard

is covering the blade before placing saw

down on bench or oor. An unprotected,

coasting blade will cause the saw to walk

backwards, cutting whatever is in its path.

Be aware of the time it takes for the blade to

stop after switch is released.

Do not expose to rain

Wear dust mask

Wear ear protection

Wear eye protection

Double insulated

Volts

Hertz

Watts

Warning

Alternating current

Revolutions, reciprocations or strokes per

minute

No load speed

/min

n

o

V

Hz

W

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Never hold piece being cut in your hands

or across your leg. Secure the workpiece

to a stable platform. It is important to

support the work properly to minimize

body exposure, blade binding, or loss of

control.

Young children should be supervised

to ensure that they do not play with the

appliance.

Do not use the tool with abrasive or

masonry/wet diamond wheels.

Only use blade diameter(s) in accordance

with the markings on the tool.

XU1 Power tools

iSC GmbH, Eschenstraße 6, D-94405 Landau, Germany

Telephone: GB: 0151 294 4488 / IRL: 1850 882711

Produktspezifikationen
