Seite 1/4
PITCHING INSTRUCT
WWW.ZEMPIRECAMPING.COM
ATLAS
/////////
CANVASSERIES
FREEDOM
CAMPING
BY
Care Instructions -
1. Ensure guy ropes are out at all times during use
2. Never pack your tent away wet. If you must take your tent down when wet, ensure that it is dried
completely as soon as possible to prevent mildew forming
3.
do not use soap or detergents
4.
5. Clean all pegs and poles before storing
6. This tent is not designed to withstand storm conditions. During strong winds, it is recommended that the
tent be taken down
7.
will shorten the life of your tent
Condensation -
It is important that lower vents are opened at all times to reduce the risk of condensation. During humid or damp
conditions, it is recommended that inner door covers are opened to expose the mesh layer to allow additional
. This will cause condensation between the
5 Year Tent Guarantee -
All our tents come with a guarantee designed to protect you as our valued customer. Flow Imports Ltd, the
makers of Zempire Camping Equipment tents, will repair or replace this tent, at their discretion should it fail due
to faulty materials or manufacture for a period of 5 years from the date of sale.
The Guarantee is subject to the following conditions:
1. The Guarantee only applies to an original purchaser who purchased this tent from an approved retail
outlet
2. The Guarantee does not apply if the tent has been used for anything other than reasonable personal
camping use. Commercial use (e.g. rental) or continuous use as a residence are expressly excluded
3. Damage due to normal wear and tear, accident, acts of God, negligence (other than by Flow Imports Ltd),
failure by the purchaser to ensure instructions for setting up and care are observed, deterioration due to
abnormal exposure to ultraviolet light, insect or mildew attack, or any other cause reasonably beyond the
control of Flow Imports Ltd are not covered
4. If redress is sought under the terms of this Guarantee, then the tent must be returned by the purchaser to
the outlet from where it was purchased within the Guarantee period, in a clean, dry state and with proof
of purchase
5. All transport costs and any other indirect costs are excluded from the Guarantee.
6. Flow Imports Ltd reserves the right to make a reasonable charge for repairs which it determines are not
within the scope of the Guarantee
7. The Guarantee does not limit, modify or exclude any rights under any law if doing so would contravene
that law or make any part of this Guarantee invalid. However, Flow Imports Ltd:
a) excludes (to the extent permitted by applicable law) all conditions and warranties that might otherwise
be implied; and
b) limits its liability for breach of any such condition or Guarantee that it cannot exclude together with its
liability under the Guarantee, to repairing or replacing the Goods or paying the cost of having the Goods
repaired or replaced (at Flow Imports’ option).
This tent has been made with meticulous care and attention to detail. Providing it’s properly looked after and
Get out more - you owe it to yourself.
POLE DIAGRAM - ATLAS
19) Extend the BLACK R4/R5
pole until the awning is tight. You
may need to lower the pole by
moving the support poles to the
side.
RB
RA
18) Insert the BLACK RB/RA
pole into the hole at the end of the
BLACK R5 pole and then through
the eyelet at the end of the
awning. Extend by pressing down
the button clip.
A1
A2
A1
A2
20) Insert the poles RED A1/A2
into the eyelets at the front corners
of the awning.
21) Guy out the front awning by
attaching the short guy ropes over
top of awning pole spikes. Line up
the guy rope with the pole spike
and the top ridge pole spike
(indicated by the Line). Ensure
the guy rope is at a 45
o
angle.
A3
A4
A3
A4
23) Peg out the front valance. The
bottom of the valance should sit
level with the ground. The outside
of the valance should align with
the outside of the tent. The inside of
the valance should be vertical.
22) Insert the longer RED A3/A4
pole into the centre of the side of
the awning. Guy out at a 45
o
angle
with the longer guy rope sections.
45
o
45
o
90
o
24) Place rubber pole feet under
support pole ( & ) BLACK RA RC
R2
R4
EB
EA
E1
EA
EB
E1
EB
EA
R3
RB
RA
EA
EB
A1
A2
A3
A4
A3
A4
R5
R1
A2
A1
E2
E2 RB
RA
RB
RA
R5
R5
R4
ATLAS
///////// CANVASSERIES
FREEDOM
CAMPING
BY
ATLAS
/////////
CANVASSERIES
FREEDOM
CAMPING
BY
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3
Line 2 - R4, R5
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
LH Eve Pole ( )GREEN
Line 1 - E1
Line 2 - E2
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1
Line 2 - E2
Line 3 - EA, EB
Line 4 - EA, EB
Awning Pole ( )RED
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs
24
Spike Washers 7
Pole Feet 2
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you first get your new tent
you will need to weather it. This is a
process of soaking the fabric to
ensure that all the thread swells up
filling stitch holes and creating a
watertight surface.
When you pitch your tent for the
first time, soak the fabric with a
garden hose until the fabric looks
visibly damp. Allow to dry and
repeat for two or three times.
Your tent will get more watertight
the more you use it. Do not be
concerned if you have a small
amount of water coming through
the seams on the first few times you
get heavy rain.
NATURAL FIBRE
Zempire canvas is made of a
combination of Natural Cotton for
breathability and water fastness
and Polyester for strength.
Please note that as Cotton is a
natural fibre, you will notice
variances of both colour and
thickness of the thread. This is
normal and is a characteristic of a
natural and breathable fibre.
FIRE RETARDANT
Zempire Canvas Tents are naturally
fire retardant. While this significantly
reduces the risk of the fabric
catching on fire, it is by no means
fireproof. Ensure open flames are
kept well away from your tent at all
times.
PACKING AWAY
YOUR TENT
1) Open up all windows and close
all doors.
2) Remove the awning poles RED
4) Remove the ridge polesBLACK
5) Remove the BLUE & GREEN
eve poles
5) Remove all pegs, clean and
place in peg bag
6) Lay tent as flat as possible and
fold the awning over main body of
the tent
7) Fold both sides into the centre
of the tent
8) Fold in half. Ensure the width is
the same as the length of your
carry bag. Adjust if necessary
9) Expel as much air as possible by
walking down the tent towards the
door
10) Roll the tent from the rear
towards the door. Ensure that you
wipe off any condensation and dirt
as you roll
DOOR
CARING FOR YOUR TENT
- Never store your tent wet
- If you must pack your tent down
while still wet, hang to dry as soon
as possible to prevent mildew
damage
- Remove dirt, tree sap, and bird
droppings with a soft brush and
warm water before packing down
- Do not use detergents to clean
your tent. This will damage the
waterproofing of the tent fabric
- When rolling up your tent ensure
there is no condensation on the
floor
- It is not advisable to re-coat your
canvas as a precautionary mea-
sure. This will reduce the breathabil-
ity and durability of your tent
Zempire canvas is pre coated and
will stay waterproof and breath-
able for many years
- When storing your tent over the
winter, do not store directly on
concrete floors
POLE CHART
- If you do get mildew forming on
your tent, remove the pours with
warm water and a soft brush to
prevent further growth
ATLAS
/////////
CANVASSERIES
FREEDOM
CAMPING
BY
