- 1 -

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2016

Thank you for selecting American Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly-please

read these instructions carefully before you begin.

RECOMMENDED TOOLS

M965762 (8/16)

ROUGHING-IN DIMENSIONS

COLONY

®

PRO

TUB AND SHOWER

INSTALLATION

INSTRUCTIONS

T075.500

T075.507

T075.508

T075.507xH

T075.508xH

Plumbers’ Putty

or Caulking

Adjustable WrenchChannel Locks

Phillips Screwdriver

Certied to comply with ANSI A112.18.1M

• To assure proper positioning in relation to wall.

Note roughing-in dimensions.

OFF

Teon Tape

Flat Blade Screwdriver

FINISHED WALL

4"

TOP OF TUB RIM

BOTTOM OF TUB

74" (1879 mm)

FOR HEAD

CLEARANCE

4-1/16"

(99 mm)

2" TO 3"

(51 TO 76 mm)

18" (457 mm)

OPTIONAL

4-7/8"

(124 mm)

5-11/16"

(144 mm)

1/2" NPT

1/2" COPPER

FOR SLIP-ON

SPOUT

7-1/2"

(190 mm)

1-1/2"

4-3/16"

(106 mm)

7-1/2"

(190 mm)

8-9/16"

(217 mm)

OPTIONAL TO FINISHED

FLOOR USUALLY

BETWEEN 65'' AND 78"

(1651 AND 1981 mm)

"SEE ILLUSTRATIONS "

THREADED INLETS (STOPS)

INLETS

1/2" NPT

5-7/8"

(149 mm)

5-7/8"

(149 mm)

5-7/8"

(149 mm)

INLETS 1/2" NPT

OUTLETS

1/2" NPT

OUTLETS

1/2" NPT

3-3/8"

(86 mm)

3-3/8"

(86 mm)

THREADED INLETS

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

4-1/16" (103 mm)

INLETS

4-1/16"

(103 mm)

4-1/16"

(103 mm)

INLETS

1/2" NOM.

COPPER

SWEAT

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

2"

SWEAT

INLETS

SWEAT

INLETS (STOPS)

INLETS

1/2" NOM.

COPPER

SWEAT

6-1/8"

(155 mm)

2-7/8"

(72 mm)
