- 1 -

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2016

Thank you for selecting American Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly-please read

these instructions carefully before you begin.

M965784 (6/17)

STUDIO

®

S

2 HANDLE THERMO MIXING

VALVE TRIM

INSTALLATION

INSTRUCTIONS

T105.740

Certied to comply with ANSI A112.18.1M

HOT

COLD

RECOMMENDED TOOLS

ROUGHING-IN DIMENSIONS

Phillips Screwdriver

Flat Blade Screwdriver

7-3/8"

(186 mm)

2" TO 2-5/8"

(48 TO 68 mm)

NOTE: FITTING

MUST BE INSTALLED

WITH VOLUME CONTROL

ON TOP.

R520

1/2" NPT INLETS

or

R540

3/4" NPT INLETS

1"

(25 mm)

FINISHED

WALL

7-7/8"

(237 mm)

7-7/16"

(189 mm)

1"

(25 mm)

2-15/16"

(74 mm)

2-7/16"

(62 mm)

1-3/4"

(45 mm)

1.7"

(43 mm)

CARE INSTRUCTIONS:

• To keep your new faucet looking new, please follow

these simple care instructions:

DO: – Simply rinse the faucet clean with clear water.

– Dry the faucet with a soft cotton cloth.

DO NOT:

– Do not use any abrasive cleaners, cloths,

or paper towels.

– Do not use any cleaning agents containing

acids, polish abrasives, or harsh cleaners

or soaps.

• Regular and routine cleaning will reduce the need for

heavy cleaning and polishing. If heavy cleaning is

required, the following procedures are recommended:

• Remove as much surface dirt and lm using clear

water and soft cotton cloth (as described above).

– Use any of the following to remove tough surface

lm and build-up:

– Mild liquid detergents

– Clear ammonia free liquid glass cleaners

– Non-acidic, non-abrasive gentle liquid or fully dissolved

powder cleansers mixed according to manufacturers

directions

– Non-abrasive liquid polishers

• Once clean, rinse faucet again with clear water to

thoroughly remove cleaner or polish and blot dry with

a soft cotton cloth.

Failure to follow these care instructions may damage

the Faucet’s finish.
