- 1 -

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2016

Thank you for selecting American Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly-please

read these instructions carefully before you begin.

RECOMMENDED TOOLS

M965724 Rev. 1.0 (7/16)

ROUGHING-IN DIMENSIONS

TOWNSEND

®

BATH AND SHOWER

TRIM KIT

INSTALLATION

INSTRUCTIONS

T353.500

T353.501

T353.502

T353.507

T353.508

Plumbers’ Putty

or Caulking

Adjustable WrenchChannel Locks

Phillips Screwdriver

Certied to comply with ANSI A112.18.1M

• To assure proper positioning in relation to wall.

Note roughing-in dimensions.

Teon Tape

Flat Blade Screwdriver

THREADED INLETS (STOPS)

5-7/8"

(149 mm)

5-7/8"

(149 mm)

INLETS 1/2" NPT

(13 mm)

INLETS

1/2" NPT

(13 mm)

OUTLETS

1/2" NPT

(13 mm)

OUTLETS

1/2" NPT

(13 mm)

3-3/8"

(86 mm)

3-3/8"

(86 mm)

3-3/8"

(86 mm)

THREADED INLETS

4"

(102 mm)

BOTTOM OF TUB

74" (1880 mm)

FOR HEAD

CLEARANCE

18" (457 mm)

OPTIONAL

6.5" REF.

(165 mm)

1/2" (12 mm) NPT

1/2" (13 mm)

COPPER

7-1/4"

(184 mm)

OPTIONAL TO FINISHED

FLOOR USUALLY

BETWEEN 65'' AND 80''

(1651 AND 2032 mm)

TOP OF TUB RIM

SHR. 1/2" (13 mm) NOM.

COPPER SWEAT

TUB 1/2" (13 mm) NOM.

COPPER SWEAT

SHR. 1/2" (13 mm) NOM.

COPPER SWEAT

TUB 1/2" (13 mm) NOM.

COPPER SWEAT

4-1/16"

(103 mm)

4-1/16"

(103 mm)

INLETS

4-1/16"

(103 mm)

2"

(51 mm)

SWEAT

INLETS

SWEAT

INLETS (STOPS)

INLETS

1/2" (13 mm) NOM.

COPPER SWEAT

INLETS

1/2" (13 mm) NOM.

COPPER SWEAT

1-5/8" TO 3-1/4"

(41 TO 83 mm)

1-5/8" TO 3-1/4"

(41 TO 83 mm)

FINISHED WALL

3.3/8" (85 mm) REF.

7" (177 mm) REF.

2-9/16"

(65 mm)

1-1/2" REF.

(38 mm)
