QUICK START GUIDE

VARIA--ACS810A 8”& 10.1” Angle-Select Tabletop Stand

VARIA--ACS150A

15.6” Angle- Select Tabletop Stand

Overview

TheAngle Varia- SelectTabletop stands are designed for 8” VARIA-, 1 800.1”

VARIAVARIA- 100, & 15.6”-150 , Touch Panelsand give them a sleek& modern

tabletop solution thatcan be installed at one of three angles to best suit the

users’ needs.

FIG. 1 Varia - Touch Panel on AngleSelectTabletop Stand

Model Availability & Compatibility

ANGLE- SELECTTABLETOP STANDS

VARIA--A ACS810

(AMX-) UMT8111

V--) ARIA80 Touch Panel (AMXUTP0811

V-- ARIA100 Touch Panel (AMXUTP1011)

V-1-ARIA00N Touch Panel (AMXUTP1011N)

VARIA--1A ACS50

(AMX- UMT1511)

V-15- ARIA0 Touch Panel (AMXUTP1511)

V-15- ARIA0N Touch Panel (AMXUTP1511N)

Other Models Available

FIXED TABLETOP STANDS

VARIA-- ACS80F

(AMX- UMT0801)

VARIA-- 80 Touch Panel (AMXUTP0811)

VARIA-- ACS100F

(AMX- UMT1001)

VARIA-- 100 Touch Panel (AMXUTP1011)

VARIA--100N Touch Panel (AMXUTP1011N)

Installation

Varia Fixed Tabletop Stands are easily installed with the supplied hardware and

a Philips- head screwdriver.

1.Place the panel face-down on a soft cloth and arrangethe panel so

that the top of the touch panel is closest to you.

FIG. 2 Varia Touch Panel, rear

2.If they are installed, remove two small screws from the lower cover.

Screw L ocations

FIG. 3 Rear cover screws, if installed

3.Place your thumbs push the on , the rectangular access holesand

lower cover away from you. Do not discard, this will be reinstalled

later.

FIG. 4 Rear Cover Removal

4.Rotate the panel back around so the bottom is closest to you.

5.Route the networking cable through the base first, and then plug the

RJ- 45 connector into the back of the touch panel.

FIG. 5 Angle-Select Tabletop Stand Base

6.Reinstall the lower cover, first snapping it into place. Optionally, two

small screws supplied in the hardware accessory bag may be

installed. Make sure the cable routes out the bottom of the lower

cover.

7.Screw the mount to the rear of the panel using the supplied screws.

FIG. 6 Mounting Plate Installation

NOTE: The three slots should be oriented UP and the set screw

holes should be oriented DOWN.

Top

Top
