Seite 1/8
AXi-FL24-R INSTALLATION MANUAL
Tech Support: 844-AXX-ESSI WWW.AXXESSINTERFACES.COM
AXi-RGB1 AXi-RGB2 AXi-RGB3
PLUG & PLAY WIRING HARNESS COMPATIBLE WITH
Rev. 4.0 081915
PLEASE REVIEW THIS INSTALLATION MANUAL
CAREFULLY BEFORE BEGINNING ANY WORK
2
Table Of Contents
………………………………….……….
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT IMPORTANT WARNING
WARNING
WARNING
WARNINGWARNING
This product includes instructions for installation which must be carefully
followed. The instructions are worded in such a manner to assume that the
installer is capable of completing these type of electronic installations. If you
are unclear as to what you are instructed to do or believe that you do not
understand the instructions so as to properly and safely complete the
installation you should consult a technician who does have this knowledge and
understanding.
Failure to follow these instructions carefully and to install the interface as
described could cause harm to the vehicle or to safety systems on the vehicle.
Interference with certain safety systems could cause harm to persons as well.
If you have any questions in this regard please call the Metra Help line at
1-844-299-3774 and for ordering questions call Metra at 1-800-221-0932.
COMPATIBLE VEHICLES/WIRING LOCATIONS…....3
PRECAUTIONS.…………………………………….....……...4
WIRING CONNECTIONS……………………….…...….....5
PLUG & PLAY HARNESS INSTALLATION……...........6
TESTING OPERATION………………………….……...…..7
VEHICLE REASSEMBLY CHECKLIST…………...…......8
3
.
COMPATIBLE VEHICLES
MAKE MODEL YEAR
FORD EXPEDITION - 2004 2006
LINCOLN AVIATOR - 2003 2005
LINCOLN - LS 2000 2006
LINCOLN NAVIGATOR - 2003 2006
LINCOLN TOWN CAR - 2003 2011
ACCESSORY GROUND REVERSE WIRE LOCATION
MAKE MODEL YEAR ACCESSORY GROUND REVERSE
FORD EXPEDITION - PIN 2. PINK PIN 13. BLK PIN 3. BLK/PNK 2004 2006
LINCOLN AVIATOR - PIN 2. BLK/PINK PIN 13. BLK PIN 3. BLK/PNK 2003 2005
LINCOLN - PIN 2. BLK/PINK PIN 13. BLK PIN 3. BLK/PNK LS 2000 2006
LINCOLN NAVIGATOR - PIN 2. PINK PIN 13. BLK PIN 3. BLK/PNK 2003 2006
LINCOLN TOWN CAR - PIN 2. PINK PIN 13. BLK PIN 3. BLK/PNK 2003 2011
Accessory, Reverse and Ground wires are found in the 24 pin connector at the navigation DVD-ROM
REAR SEAT ENTERTAINMENT VIDEO SIGNAL LOCATION
Ford Expedition, Lincoln Navigator and Lincoln Aviator RSE (Rear Seat Entertainment)
system doesn't have a video signal going outside of the RSE system. In order to connect
video output of the factory RSE, you must remove the factory RSE system from the
ceiling. Inside you will find the cable connecting DVD player and drop down monitor, in
that harness locate video signal usually yellow wire and connect RCA wire to the cable
and connect that rca to AXXESS.i interface.
Table.1
Table.2
