AXVI-9003
Volkswagen accessory and NAV output CAN harness 2002-up
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in both amplified and non-amplified systems*
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
*excluding Fender audio systems
APPLICATIONS
WIRING UP THE AXVI-9003
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the wire to the radio’s ground wire.Black
• Connect the wire to the ignition wire of the aftermarket radioRed
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the orange wire.
• The Blue wire is not used in this application.
VOLKSWAGEN
Beetle 2012-up
CC 2009-up
EOS 2007-up
Golf (with double DIN radio) 2002
Golf 2003-2006
Golf/Golf R 2010-up
GTI 2002-up
Jetta (with double DIN radio) 2002
Jetta 2003-up
Jetta GLI 2008-up
Jetta Sportwagen 2010-up
Passat 2002-up
R32 2007-2008
Rabbit 2007-2009
Tiguan 2009-up
INSTAXVI-9003
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
• Connect the wire to the left front positive speaker output of the White
aftermarket radio.
• Connect the wire to the left front negative speaker output of the White/Black
aftermarket radio.
• Connect the wire to the right front positive speaker output of the Gray
aftermarket radio.
• Connect the wire to the right front negative speaker output of the Gray/Black
aftermarket radio.
• Connect the wire to the radio’s left rear positive speaker output.Green
• Connect the wire to the radio’s left rear negative speaker output.Green/Black
• Connect the wire to the radio’s right rear positive speaker output. Purple
• Connect the wire to the radio’s right rear negative speaker output. Purple/Black
The following wires are for the aftermarket radios that have navigation built in.
• Connect the wire to the parking brake wire of the aftermarket navigation Light Green
radio (if applicable).
• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio (if applicable).
• Connect the wire to the reverse wire of the aftermarket navigation radio Green/Purple
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12 pin harness of the
AXVI-9003 and refer to the AXSWC instructions.
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
