AXDCT-2AXDCT-2

INSTALLATION INSTRUCTIONSINSTALLATIONINSTRUCTIONS

AXDCT-2AXDCT-2

INSTALLATIONINSTRUCTIONSINSTALLATIONINSTRUCTIONS

REV. 3/2/20REV. 3/2/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

REV. 3/2/20REV. 3/2/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

The AXDCT-2 should be installed on a stereo’s speaker output wires or the

output wires on an factory amplifier of up to 80 watts per channel. These

wires can be found behind the stereo in the dash, on the outside of an factory

amplifier, or on the input terminals on the factory speakers.

Wire Color & Function: The audio input wire colors are an EIA standard for car

stereo applications as follows:

Yellow - Battery +12v input †

Black - Ground input †

Blue - Remote +12v output †

† These wires can be connected directly to the amplifier being installed.

Wires only required if a 12v amp turn-on is desired.

White - Left front (+) input

White/Black - Left front (-) input

Gray - Right front (+) input

Gray/Black - Right front (-) input

Black/White - Reference ground (-)

(Reference ground optional if noise is present)

Note: Be sure that all audio input connections are polarized or in phase with

each other. That is, the positive output wires from the audio source need to be

connected to the corresponding positive input wires of the AXDCT-2. The same

goes for the negative audio wires. Failure to do this will result in poor bass

response and low quality audio.

The AXDCT-2 should be installed on a stereo’s speaker output wires or the

output wires on an factory amplifier of up to 80 watts per channel. These

wires can be found behind the stereo in the dash, on the outside of an factory

amplifier, or on the input terminals on the factory speakers.

Wire Color & Function:The audio input wire colors are an EIA standard for car

stereo applications as follows:

Yellow- Battery +12v input †

Black- Ground input †

Blue- Remote +12v output †

† These wires can be connected directly to the amplifier being installed.

Wires only required if a 12v amp turn-on is desired.

White- Left front (+) input

White/Black- Left front (-) input

Gray- Right front (+) input

Gray/Black- Right front (-) input

Black/White- Reference ground (-)

(Reference ground optional if noise is present)

Note: Be sure that all audio input connections are polarized or in phase with

each other. That is, the positive output wires from the audio source need to be

connected to the corresponding positive input wires of the AXDCT-2. The same

goes for the negative audio wires. Failure to do this will result in poor bass

response and low quality audio.

The AXDCT-2 should be installed on a stereo’s speaker output wires or the

output wires on an factory amplifier of up to 80 watts per channel. These

wires can be found behind the stereo in the dash, on the outside of an factory

amplifier, or on the input terminals on the factory speakers.

Wire Color & Function:The audio input wire colors are an EIA standard for car

stereo applications as follows:

Yellow- Battery +12v input †

Black- Ground input †

Blue- Remote +12v output †

† These wires can be connected directly to the amplifier being installed.

Wires only required if a 12v amp turn-on is desired.

White- Left front (+) input

White/Black- Left front (-) input

Gray- Right front (+) input

Gray/Black- Right front (-) input

Black/White- Reference ground (-)

(Reference ground optional if noise is present)

Note: Be sure that all audio input connections are polarized or in phase with

each other. That is, the positive output wires from the audio source need to be

connected to the corresponding positive input wires of the AXDCT-2. The same

goes for the negative audio wires. Failure to do this will result in poor bass

response and low quality audio.

The AXDCT-2 should be installed on a stereo’s speaker output wires or the

output wires on an factory amplifier of up to 80 watts per channel. These

wires can be found behind the stereo in the dash, on the outside of an factory

amplifier, or on the input terminals on the factory speakers.

Wire Color & Function:The audio input wire colors are an EIA standard for car

stereo applications as follows:

Yellow- Battery +12v input †

Black- Ground input †

Blue- Remote +12v output †

† These wires can be connected directly to the amplifier being installed.

Wires only required if a 12v amp turn-on is desired.

White- Left front (+) input

White/Black- Left front (-) input

Gray- Right front (+) input

Gray/Black- Right front (-) input

Black/White- Reference ground (-)

(Reference ground optional if noise is present)

Note: Be sure that all audio input connections are polarized or in phase with

each other. That is, the positive output wires from the audio source need to be

connected to the corresponding positive input wires of the AXDCT-2. The same

goes for the negative audio wires. Failure to do this will result in poor bass

response and low quality audio.
