AXLOC-GCAXLOC-GC

INSTALLATION INSTRUCTIONSINSTALLATIONINSTRUCTIONS

AXLOC-GCAXLOC-GC

INSTALLATIONINSTRUCTIONSINSTALLATIONINSTRUCTIONS

REV. 4/29/21REV. 4/29/21

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

REV. 4/29/21REV. 4/29/21

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

Wire Color & Function: The audio input wire colors are an EIA standard for car stereo

applications as follows.

INPUT HARNESS

White = Left front (+) input

White/Black = Left front (-) input

Gray = Right front (+) input

Gray/Black = Right front (-) input

Brown (x2) = Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXLOC-GC. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and low quality audio.

Wire Color & Function:The audio input wire colors are an EIA standard for car stereo

applications as follows.

INPUT HARNESS

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown (x2)= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXLOC-GC. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and low quality audio.

Wire Color & Function:The audio input wire colors are an EIA standard for car stereo

applications as follows.

INPUT HARNESS

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown (x2)= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXLOC-GC. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and low quality audio.

Wire Color & Function:The audio input wire colors are an EIA standard for car stereo

applications as follows.

INPUT HARNESS

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown (x2)= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXLOC-GC. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and low quality audio.

The AXLOC-GC is designed to convert speaker level audio to line level audio. This allows for the

installation of line level products such as amplifiers, EQs and crossovers on systems that do not

have RCA line level outputs.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly Found On Other

Brands of LOCs, 6:1 Step Down with Fixed Output, Gold Plated RCAs, Attractive & Durable Enclosure

TheAXLOC-GCis designed to convert speaker level audio to line level audio. This allows for the

installation of line level products such as amplifiers, EQs and crossovers on systems that do not

have RCA line level outputs.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly Found On Other

Brands of LOCs, 6:1 Step Down with Fixed Output, Gold Plated RCAs, Attractive & Durable Enclosure

TheAXLOC-GCis designed to convert speaker level audio to line level audio. This allows for the

installation of line level products such as amplifiers, EQs and crossovers on systems that do not

have RCA line level outputs.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly Found On Other

Brands of LOCs, 6:1 Step Down with Fixed Output, Gold Plated RCAs, Attractive & Durable Enclosure

TheAXLOC-GCis designed to convert speaker level audio to line level audio. This allows for the

installation of line level products such as amplifiers, EQs and crossovers on systems that do not

have RCA line level outputs.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly Found On Other

Brands of LOCs, 6:1 Step Down with Fixed Output, Gold Plated RCAs, Attractive & Durable Enclosure

2 Channel, Adjustable Line Output Converter

2 Channel, Adjustable Line Output Converter

2 Channel, Adjustable Line Output Converter

2 Channel, Adjustable Line Output Converter
