AXLOC-55SPAXLOC-55SPAXLOC-55SP

INSTALLATION INSTRUCTIONSINSTALLATIONINSTRUCTIONSINSTALLATIONINSTRUCTIONS

REV. 4/27/20REV. 4/27/20REV. 4/27/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

Wire Color & Function: The audio input wire colors are an EIA standard

for car stereo applications as follows.

INPUT HARNESS

Black = Ground

Yellow - Battery +12V input

Blue = Remote +12V output

White = Left front (+) input

White/Black = Left front (-) input

Gray = Right front (+) input

Gray/Black = Right front (-) input

Brown = Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the audio

source need to be connected to the corresponding positive input wires

of the AXLOC-55SP. The same goes for the negative audio wires. Fail-

ure to do this will result in poor bass response and low quality audio.

Adjusting the AXLOC-55SP for maximum performance: After complet-

ing all of the necessary connections, turn the AXLOC-55SP adjustment

pots all of the way down by rotating them completely counter-clock-

wise. Now, turn the stereo system on and adjust the main volume con-

trol on the stereo to approximately 3/4 maximum volume. Select one

of the adjustment pots on the AXLOC-55SP and turn it slowly clockwise

until you notice audio distortion and then stop. Turn the remaining pot

to the same position as the previously adjusted pot. The audio set-up

of the AXLOC-55SP is now complete and ready to be enjoyed.

Wire Color & Function:The audio input wire colors are an EIA standard

for car stereo applications as follows.

INPUT HARNESS

Black= Ground

Yellow- Battery +12V input

Blue= Remote +12V output

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the audio

source need to be connected to the corresponding positive input wires

of the AXLOC-55SP. The same goes for the negative audio wires. Fail-

ure to do this will result in poor bass response and low quality audio.

Adjusting the AXLOC-55SP for maximum performance:After complet-

ing all of the necessary connections, turn the AXLOC-55SP adjustment

pots all of the way down by rotating them completely counter-clock-

wise. Now, turn the stereo system on and adjust the main volume con-

trol on the stereo to approximately 3/4 maximum volume. Select one

of the adjustment pots on the AXLOC-55SP and turn it slowly clockwise

until you notice audio distortion and then stop. Turn the remaining pot

to the same position as the previously adjusted pot. The audio set-up

of the AXLOC-55SP is now complete and ready to be enjoyed.

Wire Color & Function:The audio input wire colors are an EIA standard

for car stereo applications as follows.

INPUT HARNESS

Black= Ground

Yellow- Battery +12V input

Blue= Remote +12V output

White= Left front (+) input

White/Black= Left front (-) input

Gray= Right front (+) input

Gray/Black= Right front (-) input

Brown= Reference ground (-)

(Reference ground optional if noise is present)

Note:

Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the audio

source need to be connected to the corresponding positive input wires

of the AXLOC-55SP. The same goes for the negative audio wires. Fail-

ure to do this will result in poor bass response and low quality audio.

Adjusting the AXLOC-55SP for maximum performance:After complet-

ing all of the necessary connections, turn the AXLOC-55SP adjustment

pots all of the way down by rotating them completely counter-clock-

wise. Now, turn the stereo system on and adjust the main volume con-

trol on the stereo to approximately 3/4 maximum volume. Select one

of the adjustment pots on the AXLOC-55SP and turn it slowly clockwise

until you notice audio distortion and then stop. Turn the remaining pot

to the same position as the previously adjusted pot. The audio set-up

of the AXLOC-55SP is now complete and ready to be enjoyed.

The AXLOC-55SP is designed to convert speaker level audio to line level

audio. This allows for the installation of line level products such as amplifiers,

EQs and crossovers on systems that do not have RCA line level outputs. In

addition this device will also detect the presence of an audio signal and then

generate a +12V output that can be used to turn-on an aftermarket amplifier.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly

Found On Other Brands of LOCs, 6:1 Step Down with Variable Output,

Detachable Input Plug, Gold Plated RCAs, Attractive & Durable Enclosure

The AXLOC-55SPis designed to convert speaker level audio to line level

audio. This allows for the installation of line level products such as amplifiers,

EQs and crossovers on systems that do not have RCA line level outputs. In

addition this device will also detect the presence of an audio signal and then

generate a +12V output that can be used to turn-on an aftermarket amplifier.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly

Found On Other Brands of LOCs, 6:1 Step Down with Variable Output,

Detachable Input Plug, Gold Plated RCAs, Attractive & Durable Enclosure

The AXLOC-55SPis designed to convert speaker level audio to line level

audio. This allows for the installation of line level products such as amplifiers,

EQs and crossovers on systems that do not have RCA line level outputs. In

addition this device will also detect the presence of an audio signal and then

generate a +12V output that can be used to turn-on an aftermarket amplifier.

Features:

55 Watts Maximum Input, Input Circuit Corrects Crossover Distortion Commonly

Found On Other Brands of LOCs, 6:1 Step Down with Variable Output,

Detachable Input Plug, Gold Plated RCAs, Attractive & Durable Enclosure

2 Channel, Adjustable Line Output Converter2 Channel, Adjustable Line Output Converter2 Channel, Adjustable Line Output Converter
