AXTC-A12

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/19/25 INSTAXTC-A12

ATTENTION:

With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections

LD-AX-SWCX-AU1 ................................................2

LD-AX-SWCX-AU2 ................................................3

Programming .........................................................4

Troubleshooting.....................................................5

Data Interface with SWC

Fits Select Audi Models 2002-2013

• AXTC-A12 interface

• LD-AX-SWCX-AU1 Harness

• LD-AX-SWCX-AU2 Harness

• 3.5mm Adapter

APPLICATIONS

A3 ...........................................................................................2006-2007

A4/S4 (with Symphony Radio, without NAV) ....................2002-2006

A4/RS 4/S4 .............................................................................2007-2008

A4/RS 4/S4 (with NAV) ........................................................2005-2008

A4/RS 4/S4 (with Symphony Plus or NAV radio) ........................2006

A6 .....................................................................................................2004

Allroad ...................................................................................2004-2005

TT (non-Bose) .........................................................................2002-2013

Visit AxxessInterfaces.com

for more detailed information about the product

and up-to-date vehicle specific applications

• Designed for non-amplified systems

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (Retained Accessory Power)

• Provides NAV outputs (parking brake, reverse, and speed sense)

• Built-in features like SWC & Auto-Detect

• Auto-detect feature - automatically detects the vehicle type, radio

connection, and preset controls

• Ability to dual assign steering wheel control buttons

• Designed to work with a major radio brands

• Can be manually programmed for most vehicles

• Retains settings, even after battery disconnection

• Provides 12-volt illumination output

• Retains balance & fade

• Micro “B” USB updatable
