Seite 1/2
This antenna is specically designed for indoor AM/FM radio reception,
featuring a compact and stylish housing to complement your AM/FM
radio.
Range and performance can be impacted by several external factors.
See "Tips for better reception" and "Troubleshooting" to improve
reception.
Package contents
• Balun adapter
• Antenna stand
• Power adapter
Features
• Receive AM/FM radio broadcasts, including HD
• Maximize reception and sound quality
• Easy routing with coaxial cabling
• Ensure stability with a weighted, non-slip base
• Expands connection options with balun adapter
• Built and backed by Best Buy
Mile range will vary, depending on a wide range of environmental and *Note:
geographic factors.
Setting up and using your antenna
Install this antenna near your AM/FM radio or receiver with an AM/FM
tuner.
1 Select a location to place your antenna. See “Tips for Better Reception”
for more information.
This is an indoor antenna. Do not place it outside.Note:
2 If your radio has a 75-Ohm FM connector, connect the antenna’s
coaxial cable to your radio’s 75-Ohm FM connector.
OR
If your radio has a 300-Ohm FM connector, connect the antenna’s
coaxial cable to the balun adapter, then connect the other end of the
balun adapter to your radio’s push-button or screw terminals.
3 Connect the antenna’s AM cable to your radio’s push-button or screw
terminal AM connector.
4 Connect the power adapter to the antenna’s DC 12 V input, then plug
the AC end into an AC outlet.
Note: Use only the supplied power adapter.
Before using your new product, please read these instructions to prevent any damage.
AM/FM Powered
Radio Antenna
Quick Setup Guide
BE-ANT20FM
• Antenna
• Quick Setup Guide
FM ANT
75Ω
300Ω
Rear Panel of Radio FM ANT
OR
Balun adapter
OR
Push-button
terminals
Screw
terminals
Coaxial cable
300-Ohm FM
75-Ohm FM
AM cable
Power adapter
OR
V1 ENGLISH 20-0898
5 Attach the stand to your antenna, then place it on a stable surface.
6 Turn on the radio and begin tuning.
Note: When you nish the installation, tune your radio to check the signal
strength and quality. If the quality is not good enough, move the antenna to get
the best reception.
Tips for better reception
For the best reception:
• It's better to install the antenna in a higher position that's away from
large obstacles between the antenna and transmission tower.
• Install the antenna near a window. If possible, place the antenna within
6.6 ft. (2 m) of a window.
• Keep the antenna away from sources of interference such as air
conditioners, refrigerators, computers, and microwave ovens.
• Test the antenna in multiple locations to nd the best signal.
• This antenna is an indoor antenna. Do not place it outside.
• This antenna works with any radio tuner with external antenna inputs.
See your device’s manual to check compatibility.
Legal notices
FCC Statement
1. FCC Caution - §15.21:
“Changes or modications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.”
2. FCC Statement - §15.105(b):
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
One-year limited warranty
Visit www.bestbuy.com/bestbuyessentials for details.
Contact Best Buy Essentials
For customer service, call 866-597-8427 (U.S. and Canada)
www.bestbuy.com/bestbuyessentials
Best Buy Essentials is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2021 Best Buy. All rights reserved.
Troubleshooting
Cannot nd any stations
• Make sure that all your connections are correct and secure.
• Adjust the direction and position of antenna to nd the best reception
angle.
Sound quality is good for some stations and poor or no reception for
others
• Move your antenna, then try tuning for stations again.
• Keep the antenna away from TVs and sources of interference, such as
air conditioners, hair dryers, and microwave ovens.
• Avoid placing your antenna near large metal objects or in buildings
with metal siding.
• Your antenna may be too far from the broadcast antenna to receive an
adequate signal. The signal may also be aected by obstructions
between the broadcast antenna and your antenna.
Specications
• Dimensions (H×W×D): 6.7 × 5.6 × 1 in. (17.1 × 14.3 × 2.4 cm)
• Range: 50 miles
*Note: Mile range will vary depending on a wide range of environmental and
geographic factors
• Frequency range: AM: 530~1610 KHz / FM: 88~108 MHz
• Amplier gain: FM 16±3 dB
• Output return loss: < -6 dB (88~108 MHz)
• RF output impedance: Unbalanced 75 ohm FM radio; 300 ohm
balanced
• RF coaxial cable: 1.5C-2V/ 1.8M F male
Stand
