Seite 1/16

Blizzard Lighting, LLC

www.blizzardlighting.com

Waukesha, WI USA

Page 2

TABLE OF CONTENTS

Oberon™ Fresnel LED Fixture 1

1. Getting Started 3

What’s In The Box? 3

Getting It Out Of The Box 3

Powering Up! 3

Getting A Hold Of Us 3

Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4

2. Meet The Oberon™ Fresnel LED Fixture 5

Features 5

DMX Values In-Depth 5

The Oberon™ Fresnel Pin-up Picture 6

3. Setup 7

Fuse Replacement 7

Connecting A Bunch Of Oberon™ Fresnel Fixtures 7

Data/DMX Cables 7

Cable Connectors 8

3-Pin??? 5-Pin??? Huh? 8

Take It To The Next Level: Setting up DMX Control 8

Connection With Mains 9

Mounting/Rigging 9

Installing The Barndoors 9

4. Operating Adjustments 10

The Control Panel 10

Control Panel Menu Structure 11

DMX Mode 12

Setting the DMX Address 12

Select the DMX Channel Mode 12

Master/Slave Setting 12

Loss of DMX Signal Settings 12

Perform Mode (Demo) 12

Manual Dimmer 12

Fan Settings 12

Reset Function 12

5. Appendix 13

A Quick Lesson On DMX 13

Troubleshooting 13

Keeping Your Oberon™ Fresnel As Good As New 14

Returns (Gasp!) 14

Shipping Issues 14

Tech Specs 15

Page 3

1. GETTING STARTED

What’s In The Box?

• 1 x Oberon™ Fresnel

• 1 x Barndoor Assembly

• 1 x Ever-So-Handy Power Cord

• 1 x Really Classy DMX Cable

• This Lovely User Manual

Getting It Out Of The Box

Félicitations mon ami! You’ve got yourself one incredible LED lumière. Now that you’ve

got your Oberon™ Fresnel (or hopefully, ), you should carefully unpack the box fra-nels!

and check the contents to ensure that all parts are present and in good condition. If

anything looks as if it has been damaged in transit, notify the shipper immediately and

keep the packing material for inspection. Again, please save the carton and all packing

materials. If a xture must be returned to the factory, it is important that the xture be

returned in the original factory box and packing.

Powering Up!

All xtures must be powered directly o a switched circuit and cannot be run o a

rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer

channel is used solely for a 0% to 100% switch.

AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that

the xture you receive is suitable for your local power supply. See the label on the

xture or refer to the xture’s specications chart for more information. A xture’s

listed current rating is its average current draw under normal conditions. Check the

xture or device carefully to make sure that if a voltage selection switch exists that it is

set to the correct line voltage you will use.

Warning! Verify that the voltage select switch on your unit matches the line

voltage applied. Damage to your xture may result if the line voltage applied

does not match the voltage indicated on the voltage selector switch. All

xtures must be connected to circuits with a suitable Ground (Earthing).

Getting A Hold Of Us

If something is wrong, please open a support ticket on our website at www.

blizzardlighting.com/support. We’ll be happy to help, honest.

Disclaimer: The information and specications contained in this document are subject

to change without notice. Blizzard Lighting™ assumes no responsibility or liability

for any errors or omissions that may appear in this user manual. Blizzard Lighting™

reserves the right to update the existing document or to create a new document to

correct any errors or omissions at any time. You can download the latest version of this

document from www.blizzardlighting.com.

Author: Date: Last Edited: Date:

J. Thomas 5/25/2016 J. Thomas 9/15/2016

Produktspezifikationen

Marke:	Blizzard Lighting
Kategorie:	Lichteffektmaschine
Modell:	Oberon Fresnel
Display-Typ:	LCD
Breite:	317.5 mm
Tiefe:	317.5 mm
Gewicht:	8165 g
Produkttyp:	Disco-Strahler
Produktfarbe:	Schwarz
Steuerung:	Tasten
Höhe:	425.4 mm
Energiequelle:	AC
Eingebautes Display:	Ja
Stromverbrauch (Standardbetrieb):	150 W
Anzahl:	1
Lampentyp:	LED
Eingangsspannung:	100 - 240 V
Für die Nutzung im Innenbereich geeignet:	Ja
Anzahl Lampe(n):	1 Lampen
Leuchtmittellebensdauer (in Std.):	50000 h
Beleuchtungsarten:	DMX, Master/slave, Stand-alone
Anzahl der DMX-Kanäle:	2 Kanäle
XLR-Eingang:	Ja
Anzahl Pins:	5
Eingangsfrequenz:	50/60 Hz
Kugeldurchmesser:	- "
Lampenleistung:	100 W
Lichtleistung:	8000 lm
Minimale Anzahl DMX-Kanäle:	1 Kanäle
Gewährleistungsfrist:	2 Jahr(e)
Farbtemperatur:	3200 K
