TABLE OF CONTENTS

1. Getting Started 3

What’s In The Box? 3

Getting It Out Of the Box 3

Powering Up! 3

Getting A Hold Of Us 3

Safety Instructions 4

2. Meet the Verismo™ Fresnel RGBALC 5

Main Features 5

DMX Quick Reference 5

Verismo™ Fresnel RGBALC Pin-Up Picture 6

The Rear Connections 6

3. Setup 7

Fuse Replacement 7

Connecting A Bunch of Verismo™ Fresnel Fixtures 7

Data/DMX Cabling 7

Cable Connectors 8

3-Pin??? 5-Pin??? Huh?!? 8

Take It To The Next Level: Setting Up DMX Control 8

Fixture Linking 9

Mounting & Rigging 9

4. Operating Adjustments 10

The Control Panel 10

Control Panel Menu Structure 11

Static Mode 12

Dimming Curves 12

Dimming Speed 12

Dimming Frequency 13

DMX Values In-Depth 13

5. Appendix 14

Keeping Your Verismo™ Fresnel As Good As New 14

Returns (Gasp!) 14

Shipping Issues 14

Tech Specs! 15

Page 3

1. GETTING STARTED

What’s In The Box?

• Verismo™ Fresnel RGBALC Fixture

• Power Cable

• This Lovely User Manual

Getting It Out Of the Box

Congratulations on purchasing the Verismo™ Prole WW. Now that you’ve got

your xture, you should carefully unpack the box and check the contents to

ensure that all parts are present and in good condition. If anything looks as if

it has been damaged in transit, notify the shipper immediately and keep the

packing material for inspection. Again, please save the carton and all packing

materials. If a xture must be returned to the factory, it is important that the

xture be returned in the original factory box and packing.

Powering Up!

All xtures must be powered directly o a switched circuit and cannot be run

o a rheostat (variable resistor) or dimmer circuit, even if the rheostat

or dimmer channel is used solely for a 0% to 100% switch.

Warning! All xtures must be connected to circuits with a suitable

Ground (Earthing).

Getting A Hold Of Us

If something happens to go wrong, visit blizzardpro.com/support and

open a support ticket. We’ll be happy to help, honest.

Disclaimer: The information contained in this document are subject to change without

notice. Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions

that may appear in this user manual. We reserve the right to update the existing, or create

a new document to correct any errors or omissions at any time. You can download the

latest version of this document from www.blizzardpro.com.

Author: Date: Last Edited: Date:

J. Thomas 1/24/2022 J. Thomas 1/29/2024

Produktspezifikationen

Marke:	Blizzard Lighting
Kategorie:	Lichteffektmaschine
Modell:	Verismo Fresnel RGBALC
Breite:	444.5 mm
Tiefe:	482.6 mm
Gewicht:	2404.04 g
Produkttyp:	Disco-Stroboskoplicht
Produktfarbe:	Schwarz
Höhe:	177.8 mm
Energiequelle:	AC
Zertifizierung:	ETL, CE, RoHS
Stromverbrauch (Standardbetrieb):	156 W
LED-Anzeigen:	Ja
Anzahl:	1
Lampentyp:	LED
Eingangsspannung:	100 - 240 V
Für die Nutzung im Innenbereich geeignet:	Ja
Beleuchtungsarten:	DMX
Anzahl der DMX-Kanäle:	9 Kanäle
DMX-Eingang:	Ja
DMX-Ausgang:	Ja
Anzahl Pins:	5
Eingangsfrequenz:	50 - 60 Hz
Kugeldurchmesser:	- "
Lampenleistung:	200 W
Minimale Anzahl DMX-Kanäle:	6 Kanäle
Farbwiedergabeindex (CRI):	90
Flimmerfreier Betrieb:	Ja
Integrierter Griff:	Ja
