ACM500 QUICK REFERENCE GUIDE
01Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
ACM500
Quick Reference Guide
Our UHD SDVoE Multicast distribution platform allows distribution of the highest
quality, uncompromised 4K with zero latency Audio/Video over copper or optical
fibre 10GbE networks.
The ACM500 Control Module features advanced third party control of the SDVoE
10GbE Multicast system using TCP/IP, RS-232 and IR. The ACM500 includes a web
interface module for control and configuration of the Multicast system and features
‘drag and drop’ source selection with video preview and independent routing of IR,
RS-232, USB / KVM, Audio and Video. Pre-built Blustream product drivers simplify
Multicast product installation and negate the need for an understanding of complex
network infrastructures.
Introduction
FEATURES:
• Web interface module for configuration and control of the Blustream SDVoE 10GbE Multicast system
• Intuitive ‘drag & drop’ source selection with video preview feature for active monitoring of system status
• Advanced signal management for independent routing of IR, RS-232, CEC, USB/KVM, audio and video
• Auto system configuration
• 2 x RJ45 LAN connections to bridge existing network to Multicast video distribution network, resulting in:
- Better system performance as network traic is separated
- No advanced network setup required
- Independent IP address per LAN connection
- Allows simplified TCP / IP control of Multicast system
• Dual RS-232 ports for control of the Multicast system or pass-through of control to remote third party devices
• 5V / 12V IR integration for control of Multicast system
• PoE (Power over Ethernet) to power Blustream product from PoE switch
• Local 12V power supply (optional) should Ethernet switch not support PoE
• Support for IOS and Android App control
• 3rd party drivers available for all major control brands
Produktspezifikationen
| Marke: | Blustream |
| Kategorie: | Nicht kategorisiert |
| Modell: | ACM500 |
| Breite: | 190.4 mm |
| Tiefe: | 93 mm |
| Gewicht: | 600 g |
| Übertragungstechnik: | Kabelgebunden |
| Höhe: | 25 mm |
| Energiequelle: | Gleichstrom |
| Gleichstrom-Anschluss (DC): | Ja |
| Betriebstemperatur: | 0 - 40 °C |
| Power over Ethernet (PoE): | Ja |
| Typ: | AV-Sender & -Empfänger |
| Temperaturbereich bei Lagerung: | -20 - 60 °C |
| Ein-/Ausschalter: | Ja |
| Eingangsstrom: | 1 A |
| Arbeitsspannung: | 12 V |
| unterstütze Kabeltypen: | HDMI |
| RS-232 Eingangs-Ports: | 2 |
| RJ-45-Eingangsanschlüsse: | 2 |
| IR-Durchgang (Pass Through): | Ja |
| RS-232-Durchschleifung: | Ja |
