DA22OPTQUICK REFERENCE GUIDE

01

Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk

Our DA22OPT has been designed to both encode 2ch optical S/PDIF audio to a Dante®

digital signal, and decode a Dante® digital signal to 2ch optical S/PDIF audio. The DA22OPT

is a plug & play device that is powered using PoE (Power Over Ethernet). The DA22OPT also

supports AES67 RTP audio transport.

Introduction

DA22OPT

Quick Reference Guide

• Encodes 2ch optical S/PDIF audio to a Dante® digital signal

• Decodes a 2ch Dante® digital signal to optical S/PDIF audio

• Supports: 44.1, 48, 88.2 & 96 KHz sample rates @ 16, 24 & 32 Bit

• Configurable Dante® device latency (supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller)

• +6dB / -24dB input sensitivity and output gain control adjustment

• Supports AES67 RTP audio transport

• Features Class 0 802.3af PoE for powering of product from any PoE switch

• Local 12v power supply input for when network switch does not support PoE*

* PS121PH power supply sold separately

FEATURES:

Connections:

1DC Input - Connect to +12VDC power supply (not supplied) if device is not powered via a PoE switch

2Dante® Audio Input/Output - RJ45 socket connects Dante® network and powers device via PoE

3Optical S/PDIF Digital Input - 2ch optical digital audio input to Dante®

4Optical S/PDIF Digital Output - 2ch optical digital audio output from Dante®

5Reset Switch - Press and hold to reset device

Front Panel

1

Rear Panel

4

Side Panel

352
