RX150CS QUICK REFERENCE GUIDE
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
RX150CS
Quick Reference Guide
Our RX150CS HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 HDBaseT™ ARC Receiver
oers market leading features and outstanding value utilising CSC technology.
The product extends HDMI, Bi-directional IR & RS-232 and is powered by the Matrix
up to lengths of 150m (4K to 100m). The RX150CS Receiver features ARC support
and Ethernet pass through when used with compatible Blustream hardware and
simultaneous analogue stereo and Optical Toslink audio breakout.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
• Supports 4K 60Hz 4:4:4 UHD video up to 100m
• Extends HDMI 1080p video up to 150m (HDBaseT™ long reach mode)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Automatic downscaling of up to 4K 60Hz 4:4:4 video input to 1080p
• Supports ARC (Audio Return Channel) from connected display via HDMI or Optical digital inputs (when used with
compatible Blustream Transmitter / Matrix)
• Bi-directional Ethernet pass through when used with compatible Blustream Transmitter or Matrix solution.
• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Bi-directional RS-232 pass-through
• Supports bi-directional IR pass-through to compatible HDBaseT™ device
• Supports PoC (Power over Cable) from Blustream Matrix or Transmitter products
• HDCP 2.2 support
ONOFF5V12V
OPT
HDMICTRLFW
PLA
HDMI
OPT IN
LRMARCRS-232IR
HDBT INETHERNETRS-232
TXRX
IR INIR OUTHDMI OUTOPT OUTL/R OUT
24V 1.25A
