GB – User’s Manual
Thermography bench
C.A 1875
C.A 1875
2
You have just purchased a C.A 1875 thermography tutorial bench and we thank
you for your confidence.
For best results from your instrument:
• read these operating instructions carefully,
• observe the precautions for use
MEANINGS OF THE SYMBOLS USED
Selective sorting of wastes for the recycling of electrical
and electronic equipment within the European Union.
In accordance with directive WEEE 2002/96/EC: this
equipment must not be processed as household waste.
Possible hazard. Refer to the operating instructions before
using the device.
The CE marking guarantees conformity with European
directives and with regulations concerning EMC.
Attention, hot surface
PRECAUTIONS FOR USE
If this device is damaged or a part is missing, please immediately contact the seller.
Non-observance of the instructions or of the precautions for use may impair the
protection provided by the device.
Refer to these instructions concerning each danger symbol encountered.
C.A 1875
3
CONTENTS
1. INTRODUCTION ............................................................................................... 4
2. PRESENTATION ............................................................................................... 5
3. CHARACTERISTICS ........................................................................................... 7
3.1 GENERAL CHARACTERISTICS OF THE BENCH 7........................................................
3.2 CHARACTERISTICS OF THE FUSE ........................................................................ 8
4. COMMISSIONING ............................................................................................ 8
5. MANIPULATIONS 9............................................................................................
5.1 TRANSFERS THERMAL .............................................................................. 9
5.1.1 Theory .............................................................................................. 9
5.1.2 Manipulations: study of the influence of emissivity ...................... 15
5.2 STUDY OF THE REAL BODY ............................................................................. 16
5.2.1 Theory ............................................................................................ 16
5.2.2 Manipulations: study of the influence of reflection and transmission
....................................................................................................... 18
5.3 THERMOGRAPHY RA OPTICS AND CAME ................................................ 18
5.3.1 Theory: study of the spatial resolution. ......................................... 18
5.3.2 Manipulation: study of spatial resolution. ..................................... 22
5.4 MANIPULATIONS ON SOFTWARE .......................................................... 23
5.5 THERMOGRAPHY IN PRACTICE .............................................................. 25
5.5.1 Fault determination modes. .......................................................... 25
5.5.2 Applications ................................................................................... 26
5.6 19 PRODUCING A Q REPORT .......................................................................... 28
5.6.1 Presentation .................................................................................. 28
5.6.2 Application ..................................................................................... 31
6. MAINTENANCE .............................................................................................. 31
6.1 R EPAIR ..................................................................................................... 31
6.2 CHANGE OF FUSE ................................................................................... 32
7. WARRANTY ................................................................................................... 32
8. TO ORDER ..................................................................................................... 32
APPENDIX 1: DETERMINATION OF EMISSIVITY .................................................. 33
APPENDIX 2: DETERMINATION OF REFLECTED TEMPERATURE .......................... 34
APPENDIX 3: APPLICATION EXERCISES .............................................................. 35
APPENDIX 4: SOLUTIONS .................................................................................. 41
