Seite 1/4
CDR-31C Cargo Camera CDR-02 Tailgate Handle Camera CUB-15 Adjustable Angle Side Camera
RFM-UC1
Multi View Integration Interface with A/V Input for
DODGE, JEEP & RAM Vehicles with Uconnect 8.4” Systems
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
Crux Interfacing Solutions • 6860 Canby Ave., Suite 104, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.013019
1 of 4
- Adds a reverse camera input, plus 5 video inputs and an addional audio/video input.
- Uses the steering wheel control buons to toggle between video sources. (except OEM backup camera. See page 3)
- Turn signals automacally trigger the corresponding side camera.
- Turn signal camera trigger can be turned on or o by using the BACK buon on the radio.
PRODUCT FEATURES:
PARTS INCLUDED:
RFM-UC1Module RFM-UC1 Harness
OPTIONAL ADD-ON CAMERAS:
Oponal add on cameras are available to complete the mul-view capability of the RFM-UC1. Cameras available
and include:sold separately
CFF-01 Bullet Type Front Camera CFF-02 Square Body Front Camera CFF-03 Grille Mount Front Camera
Crux Interfacing Solutions • 6860 Canby Ave., Suite 104, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.013019
2 of 4
INSTALLATION DIAGRAM:
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
Front Camera Input
Right Camera Input
Left Camera Input
Cargo Camera Input
Aftermarket Backup Camera Input
Trailer Camera Input
Audio/Video
Input
Front and Rear Camera Power Output 12V (purple/white)
Left and Right Camera Power Output 12V (green/white)
Cargo and Trailer Camera Power Output 12V (orange/white)
Video AUX Power Output 12V (red/white)
To Vehicle Harness
To Radio
Connect this 6-pin plug if OEM
backup camera is being used
DIP SWITCH SETTINGS:
DIP# ON OFF
1No Funcon – Leave OFF
2 Front Camera ON Front Camera OFF
3Le Camera ON Le Camera OFF
4 Right Camera ON Right Camera OFF
5 Cargo Camera ON Cargo Camera OFF
6 Trailer Camera ON Trailer Camera OFF
7AUX A/V ON AUX A/V OFF
8 Set to ON
RFM-UC1
Multi View Integration Interface with A/V Input for
DODGE, JEEP & RAM Vehicles with Uconnect 8.4” Systems
Crux Interfacing Solutions • 6860 Canby Ave., Suite 104, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.013019
3 of 4
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
OPERATION:
1. Whether an aermarket or OEM backup camera is used,
pung the gear in reverse will automacally show the
backup camera image on the screen.
2. Pung the gear to drive aer the reverse process
turns on the front camera for 7 seconds.
3. Using the le and right turn signal triggers the respecve
side mirror mounted camera to show on the screen.
4. To turn o the automac triggering of the side mirror
cameras, move the turn signal switch to the camera to
be turned o and press the BACK buon on the radio for
3-5 seconds. Repeat the process to turn it back on. With
the turn signal switch in nuetral, the same buon turns
on the VIM feature.
5. To force view the cameras installed, press and hold the rear
right side steering wheel control middle buon to toggle through
the dierent cameras. (Forced view of the backup camera is
only available if using an aermarket backup camera.) While in
reverse gear, press and hold the same buon to toggle between
reverse camera and video input (i.e cargo or trailer camera).
6. To use the AV input, press and hold the le rear side
steering wheel control middle buon to toggle to AV
mode. Audio plugged in the AV RCAs will automacally
be heard through the OE audio system. No need to plug
to the AUX input of the vehicle.
RFM-UC1
Multi View Integration Interface with A/V Input for
DODGE, JEEP & RAM Vehicles with Uconnect 8.4” Systems
