2. Align Vehicle Seat Rail Clamp and the Carbon

Allen Key

Screw

Fiber Vechicle Mount and Screw as shown in

diagram above. Use Allen Key to screw together.

2. Installing Vehicle Seat Rail Clamp to the

Carbon Fiber Vechicle Mount

Because each vehicle is different, you will need to determine which included seat rail clamp is best for you.

1. Choose the base with the

angle that matches your needs.

for 7-14 Inch Tablets

AUT-CFVM

Carbon Fiber Vehicle Mount

Please be sure to fasten all the screws were tightened securely while using the stand.

Not for use while driving.

Max loading :1KG

!

Caution

Package Contents:

3.Installing Carbon Fiber Vechicle Mount to your Vechicle Seat Rail

4.Adjusting the Flex Arm

1. Twist the SCREW KNOB(both or Either)

anticlockwise to release the connection.

2. Adjust the arm to your favorite position and then

tighten the SCREW KNOB clockwise .

4

Foam Pads

2.Tablet holder rotates 360 degrees for

custom viewing angles.

1.Press quick release button on side of tablet holder to release the

adjustable end. Insert tablet corner against the spring arm, then push

adjustable arm down against opposite corner. Be sure it is as snug

as possible.

360 rotation˚

5. Installing your Device and Adjusting the Tablet holder

Carbon Fiber Vehicle Mount

Hex. Allen KeyScrew M10x12L

180°90°45°

Vehicle Seat Rail Clamps

Instructions:

Foam Pad

Thickness

Tablet

Thickness:

1mm 0.67-1.06in

5mm0.51-0.91in

10mm0.31-0.71in

17-27mm

13-23mm

8-18mm

Use this table to determine the appropriate

foam pad to use with your tablet.

Note: sizes refer to total tablet size with or without a case.

/

/

/

Select the appropriate foam pad according to the

thickness of your tablet (or tablet in its case), then

press adhesive side into center of the tablet holder.

1mm Foam Pad

5mm

Foam

Pad

10mm

Foam

Pad

1.Attaching Foam Pad to Tablet Holder

1.Loose the bolt of the seat rail.

2.Install the assembled Vechicle Seat Rail

Clamp and Base set on the seat rail and

screw back the bolt.
