3. Attaching Foam Pad to Tablet Holder

Gooseneck Chair Clamp

PAD-CHAIRPB - PAD-CHAIRPW

INSTRUCTION - MANUAL

CONTENTS:

INSTALLATION:

888-733-4448

1A. Align the base (A) with

the gooseneck (B).

2A. Align both sides of the hoop (A and C) to the

chairs cylinder.

2B. While holding the (4) Hex Nuts (B) in the back,

align the Washers (F) and the (4) Bolts (D) with the

holes. Use the included Allen Key (G) tool to screw

the (4) Bolts until securely tightened.

1B. While aligned, rotate the goosenecks base

(B) until completely secured.

1C. Rotate butterfly knob to securely fasten

gooseneck (B) to body (A).

1. Connecting Base with Gooseneck

2. Attaching Base to Chair

x1

F

Washer

x4

Hex Nut

x4

E

Bolt

x4

D

Base

A

Outer Clamp

x4

C

Allen Key

x1

GH

2 Keys

x1

B

A

G

E

A

D

F

C

B

A

B

A

A

**Chair shown for

example and NOT included

x1

Gooseneck &

Tablet Holder

B

3A. Select the appropiate foam pad (I) according to the thickness of your tablet (or tablet in

its case), then press adhesive side into center of the tablet holder.

- Use this table to determine the appropiate

foam pad (B) to use with your tablet.

Note:

sizes refer to total tablet size with or

without a case

Tablet Thickness:

Foam Pad

Thickness:

1mm0.67-1.06in / 17-27mm

0.51- 0.91in / 13-23mm

0.31- 0.71in / 8-18mm

5mm

10mm

I

B

1mm

5mm

10mm

Foam Pads

x3

1mm

5mm

10mm

I
