Multi-Gigabit Ethernet Switch Series

DMS-1250 Series

Version 1.00 | 12/19/2023

Web UI Manual

D-Link DMS-1250 Series User Manual

Table of Contents

Table of Contents ............................................................................................................................................. i

About This Guide ............................................................................................................................................. 1

Terms/Usage .................................................................................................................................................. 1

Copyright and Trademarks ............................................................................................................................ 1

1 Product Introduction ................................................................................................................................... 2

DMS-1250-10S .............................................................................................................................................. 3

Front Panel ................................................................................................................................................. 3

Rear Panel .................................................................................................................................................. 3

DMS-1250-10SP ............................................................................................................................................ 4

Front Panel ................................................................................................................................................. 4

Rear Panel .................................................................................................................................................. 5

DMS-1250-12TP ............................................................................................................................................ 5

Front Panel ................................................................................................................................................. 5

Rear Panel .................................................................................................................................................. 6

2 Hardware Installation .................................................................................................................................. 7

Safety Cautions .............................................................................................................................................. 7

Step 1: Unpacking .......................................................................................................................................... 8

Step 2: Switch Installation .............................................................................................................................. 8

Desktop or Shelf Installation ....................................................................................................................... 8

Rack Installation ......................................................................................................................................... 8

Step 3 – Plugging in the AC Power Cord ....................................................................................................... 9

Power Failure ............................................................................................................................................. 9

Grounding the Switch ................................................................................................................................. 9

3 Getting Started ........................................................................................................................................... 11

Management Options ................................................................................................................................... 11

Using Web-based Management .................................................................................................................. 11

Supported Web Browsers ........................................................................................................................ 11

Connecting to the Switch .......................................................................................................................... 11

Login Web-based Management ............................................................................................................... 11

Smart Wizard ............................................................................................................................................... 12

Web-based Management ............................................................................................................................. 12

4 Configuration ............................................................................................................................................. 13

Smart Wizard Configuration ......................................................................................................................... 13

IPv4 Information ....................................................................................................................................... 13

SNMP Settings ......................................................................................................................................... 13

User Accounts Settings ............................................................................................................................ 14

Web-based Management ......................................................................................................................... 15

Tool Bar > Save Menu ................................................................................................................................. 15

Save Configuration ................................................................................................................................... 15

Tool Bar > Tool Menu .................................................................................................................................. 16

Firmware Information................................................................................................................................ 16

Configuration Information ......................................................................................................................... 16

Firmware Upgrade & Backup > Firmware Upgrade from HTTP .............................................................. 17

Firmware Upgrade & Backup > Firmware Upgrade from TFTP ............................................................... 17

Firmware Backup to HTTP & Backup > Firmware Backup to HTTP ........................................................ 17

Firmware Backup to HTTP & Backup > Firmware Backup to TFTP ........................................................ 17

Configuration Upgrade & Backup > Configuration Restore from HTTP ................................................... 17
