Seite 1/143

DXS-1100 Series 10 Gigabit Ethernet Switch

User Manual

Information in this document is subjected to change without notice.

Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly

forbidden.

Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft

and Windows are registered trademarks of Microsoft Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. D-Link Corporation disclaims any proprietary interest in trademarks and

trade names other than its own.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with this manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the interference at his

expense.

Warning: Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user authority to operate the equipment.

CE Mark Warning

This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio

interference.

VCCI Warning

この装置は、クラス A 情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こすことがあ

ります。この場合には使用者が適切な対策を講ずるよう要求されることがあります。 VCCI-A

BSMI Notice

此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻擾動，在此種情況下，使用者會被要求採取某

些適當的對策。

Safety Compliance

Warning: Class 1 Laser Product.

• EN: When using a fiber optic media expansion module, never look at the transmit laser while it is

powered on. Also, never look directly at the fiber TX port and fiber cable ends when they are

powered on.

• FR: Ne regardez jamais le laser tant qu’il est sous tension. Ne regardez jamais directement le port

TX (Tramsmission) à fibres optiques et les embouts de câbles à fibres optiques tant qu’ils sont sous

tension.

SFP (Mini-GBIC), XENPAK, and XFP Regulatory Compliance

Networks pluggable optical modules meet the following regulatory requirements:

• Class 1.

• IEC/EN60825-1:2007 2nd Edition or later, European Standard

• FCC 21 CFR Chapter 1, Subchapter J in accordance with FDA and CDRH requirements.

• Application of CE Mark in accordance with 2004/108/EEC EMC Directive and the 2006/95/EC Low

Voltage Directives.

• UL and/or CSA registered component for North America.

• 47 CFR Part 15, Class A when installed into products.

Produktspezifikationen

Marke:	D-Link
Kategorie:	Schalter
Modell:	DXS-1100-16SC
Produktfarbe:	Schwarz
Verpackungsbreite:	388 mm
Verpackungstiefe:	506 mm
Verpackungshöhe:	90 mm
Paketgewicht:	4163 g
Netzstandard:	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Zertifizierung:	cUL, CB, CE, CCC, BSMI
Stromverbrauch (Standardbetrieb):	60 W
Power over Ethernet (PoE):	Nein
Warentarifnummer (HS):	85176990
Switch-Typ:	Managed
MAC-Adressentabelle:	16000 Eintragungen
Routing-/Switching-Kapazität:	210 Gbit/s
Rack-Einbau:	Ja
Anzahl Combo-SPF-Anschlüsse:	2
Palettenlänge (brutto):	1100 mm
Palettenbreite (brutto):	1200 mm
Stapelbar:	Nein
Versandkartonsbreite:	198 mm
Versandkartonslänge:	524 mm
Versandkartonshöhe:	420 mm
Gewicht (innerer) Versandkarton:	9136 g
Menge pro Versandkarton:	2 Stück(e)
Nettogewicht Versandkarton:	8326 g
Palettenbruttogewicht (Luft):	463528 g
Anzahl der Kartons pro Palette (Luft):	48 Stück(e)
Anzahl pro Palette (Luft):	96 Stück(e)
Palettenhöhe (Luft):	1815 mm
Palettenbruttogewicht (Meer):	463528 g
Anzahl der Kartons pro Palette (See):	48 Stück(e)
Anzahl pro Palette (See):	96 Stück(e)
Palettenhöhe (See):	1815 mm
Menge Modul-Steckplätze SFP+:	14
