1 GENERAL DESCRIPTION AND SPECIFICATIONS
The Model 10A63-2 is a high-accuracy conditioner allowing input of one or two exter-
nal voltage signals
. Mixed as desired, these may originate from DC-to-DC LVDT’s,
potentiometer-type sensors, and other 2-, 3-, or 4-wire analog signal sources, either
grounded or floating—or they may represent the outputs of other instrument systems
having various voltage levels and grounding configurations.
The 10A63-2 offers a wide range of input voltages. Its differential inputs, generous
common-mode range, and excellent common-mode rejection eliminate ground-cou-
pling errors and other problems normally associated with off-ground signal sources.
Nominal 5 V-DC excitation is provided for external sources that require it. “1/2 Bridge
Completion” terminals allow “zero-center” operation of potentiometers with resistance
from 1 to 10 kΩ.
ADDITIONAL 10A63-2 SPECIFICATIONS
Transducer Types
: 2-, 3-, or 4-wire DC voltage sources, grounded or floating
Input Voltage Ranges: ±0.05, 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50, 100, or 200 V-DC; auto-
matically selected—on an individual channel basis—when the channel is configured;
for the System 10 channel “type” codes assigned to 10A63-2 data channels, see
Table 1, below
Excitation (per channel): Nominal 5 V-DC; 50 mA, maximum
Amplifier (per channel):
Normal-Mode Range: ±200 V operating; ±500 V without instrument damage
Common-Mode Range: ±200 V operating; ±300 V without instrument damage
Common-Mode Rejection Ratio: DC: -120 dB; at 60 Hz: -60 dB
Input Impedance: Differential: 1 MΩ; Common-Mode: 0.5 MΩ
Offset: Initial: ±0.02% of full scale; vs. Temperature: ±50 ppm/°C; vs. Time: ±20
ppm/month
Gain Accuracy: ±0.02% of full scale typical, following calibration*
Gain Stability: vs. Temperature: ±50 ppm/°C; vs. Time: ±50 ppm/month
(cont’d)
* Initial (uncalibrated) inaccuracy may be as great as ±1.5% of full scale. Maximum error that
could occur upon replacement of a Model 10A63-2 not followed by calibration is ±3% of full
scale.
GENERAL DESCRIPTION AND SPECIFICATIONS 10A63-2.1
SYSTEM 10
ANALOG INPUT CARDS
1.E.2.10A63-2
MODEL 10A63-2
DUAL VOLTAGE
CONDITIONER CARD
Filter (per channel): 3-pole modified Butterworth; 3 dB down at 5 Hz; 60 dB down at
100 Hz
Step-Response Settling Time (Full-Scale Output):
To 1% of final value: 200 msec
To 0.1% of final value: 300 msec
To 0.02% of final value: 400 msec
Auxiliary Outputs: Filtered outputs available on mainframe wire-wrap pins
Table 1 10A63-2 “Type” Codes
Full-Scale Channel
Range Type Code
±50 mV-DC 61
±100 mV-DC 60
±200 mV-DC 62
±500 mV-DC 64
±1 V-DC 63
±2 V-DC 65
±5 V-DC 67
±10 V-DC 66
±20 V-DC 68
±50 V-DC 6A
±100 V-DC 69
±200 V-DC 6B
2 TRANSDUCER CONNECTIONS
The Model 10A63-2’s I/O CONNECTOR mates with Daytronic CONDITIONER CON-
NECTOR No. 60322, shown in Fig. 1.5 (in Manual Section 1.E.1). Table 2 gives stan-
dard pin assignments for the I/O Connector.
2-wire cabling for analog sources with no excitation from the 10A63-2 is given in Fig.
1(a);
3-wire zero-to-full-scale potentiometer cabling is given in Fig. 1(b); 3-wire zero-
center potentiometer
cabling is given in Fig. 1(c); and 4-wire DC-to-DC LVDT cabling is
given in Fig. 1(d).
Note that floating (ungrounded) inputs are to be grounded at the site of the signal
source
, and not at the CONDITIONER CONNECTOR. Note also that the Model 10A63-
2 has “1/2 BRIDGE COMPLETION” terminals to allow bipolar (“Zero Center”) operation
of potentiometers. As shown in Fig. 1(c), the 1/2 BRIDGE is powered by the poten-
tiometer excitation. Although this excitation is normally supplied by the 10A63-2—as
shown in the figure—the user may replace it with his own precision source, if desired.
In this case,
Pins 1 and A (for Channel 1) or Pins 6 and F (for Channel 2) would not
be used. The 1/2 BRIDGE terminals would tie into the user’s excitation lines (Pin 2 or 7
to +EXCITATION; Pin B or H to –EXCITATION).
10A63-2.2 TRANSDUCER CONNECTIONS
10A63-2 DUAL DC VOLTAGE CARD
