ASD:1001 HF Drivers

** Multiple units exceeded published power rating evaluated under EIA-426B specication while mounted on Eminence’s H290 or H290S horn in a non-temperature controlled environment.

*** The average on axis output across the entire usable frequency range when mounted to the H290 or H290S horn and applying 1W/1m into the nominal impedance, i.e. 2.83V/8Ω, 4V/16Ω. Eminence response curves are

measured under the following conditions: All speakers are tested at 1W/1m using a variety of test set-ups for the appropriate impedance | LMS using 0.25” supplied microphone (software calibrated) mounted 1m from wall/

bafe | 2ft x 2ft bafe is built into the wall with horn front mounted | Carver PM-120 amplier | 2700ft3 chamber with berglass on all six surfaces (three with custom-made wedges).

Throat Size

Nominal Impedance

Power Rating**

Free Air Resonance

Usable Frequency Range

Recommended Crossover

Sensitivity***

Magnet Weight

Voice Coil Diameter

Re

Minimum Impedance

1”, 25.4mm

8 ohms

50W (EIA-426A specication

w/ xover ≥ 2.5kHz @ 18dB/octave

1.2kHz

2.5kHz-20kHz

18dB/oct @ 2.5kHz

104.4dB (1W/1m across 2.5kHz-20kHz on

axis on H290S horn)

12 oz., 0.34kg

1.3”, 33mm

6.7 ohms

7.7 ohms @ 3kHz

Specication

Overall Diameter

Mounting Thread

Depth

Weight

Volume

3.5”, 88.9mm

1 3/8” 18 UNEF ext.

2.45”, 62.2mm

2 lbs, 0.9 kg

15.84 cu.in.

Mounting Information

Also available in bolt-on format (ASD:1001B)

Materials of Construction

Voice Coil Former

Diaphragm Material

Magnet Composition

Aluminum

Titanium

Ferrite

ASD:1001 measured on Eminence H290S horn.
