File: DeltaPro12SmallMidHighBox400Watts.bb6

DeltaPro12 Small Mid/Hi Sat Box or Hi Pwr Floor Wedge

By McJerry, Eminence Speaker LLC

Displacement and thermally limited to 400 watts. Must use a 24 dB per octave high pass filter set to 100 Hz or higher

to protect woofer from overexcursion. Great for a 12" Two-way mid/high or a hi-power floor monitor.

Box Properties

--Description--

Name:

Type: Vented Box

Shape: Prism, square (optimum)

--Box Parameters--

Vb = 1 cu.ft

V(total) = 1.096 cu.ft

Fb = 95 Hz

QL = 7

F3 = 86.52 Hz

Fill = minimal

--Vents--

No. of Vents = 3

Vent shape = round

Vent ends = one flush

Dv = 2.253 in

Lv = 0.75 in

Driver Properties

--Description--

Name: Delta Pro-12

Type: Standard one-way driver

Company: Eminence Speaker LLC

Comment: Revised NOV 2005

Piston: Paper cone.

Suspension: Cloth surround.

Dust Cap: Solid composition paper dust cap.

Frame: Diecast aluminum basket.

Voice Coil: 2.5 inch (63.5 mm) AL Wire. Kapton former.

Magnet: 80 oz ferrite magnet.

--Configuration--

No. of Drivers = 1

--Mechanical Parameters--

Fs = 51 Hz

Qms = 7.56

Vas = 81.7 liters

Cms = 0.21 mm/N

Mms = 48 g

Rms = 2.02 kg/s

Xmax = 4.55 mm

Xmech = 13.65 mm

P-Dia = 258.1 mm

Sd = 532.4 sq.cm

P-Vd = 0.238 liters

--Electrical Parameters--

Qes = 0.37

Re = 5.71 ohms

Le = 0.84 mH

Z = 8 ohms

BL = 15.3 Tm

Pe = 400 watts

--Electromech. Parameters--

Qts = 0.35

no = 2.824 %

1-W SPL = 96.66 dB

2.83-V SPL = 98.12 dB
