Copyright
©
2014 EtherWAN Systems, Inc. Page 1
All Rights Reserved
EX29000 rev. 1.0
12/29/2014
1 Unpacking
Unpack the items. Your package should include:
One EX29000 Series switch
Rack-mounting hardware brackets
One CD containing this user’s guide
If items are missing or damaged, notify your
EtherWAN representative. Keep the cartonand
packing material.
2 What Else You Need
Appropriate cables for dataports
Personal computer or laptop
3 Selecta Location
Desktop installations: Mount ona flat table
or shelf surface.
Rack installations: Use a 19-inch (48.3-
centimeter) EIA standard equipment rack
that is grounded and physically secure.
Identifya power source within 6 feet (1.8
meters).
Choose a dry area with ambient temperature
between -10 and 60ºC (14 and 140ºF).
Keep away from heat sources, sunlight, warm
air exhausts, hot-air vents, and heaters.
Be sure there is adequate airflow.
Keep the switch at least 6 ft (1.83 m) away
from the nearest source of electromagnetic
noise, such as a photocopy machine.
4 Connect to the DataPorts
Depending on the model, your switch can have
the following ports:
0, 8, 16, or 24 10/100Base-TX ports
0, 4, 8, 12, 16, 20, or 24 100Base-FX ports
0, 2, or 4 Gigabit ports
10/100Base-TX and 100Base-FXPorts
Theseports can connect todevices such as an IP
surveillance camera or a Voice Over Internet
Protocol (VoIP) phone.
A.Insert one end of a Category 5 or better
Ethernet cable into a switch port.
B.Connect the other end into the Ethernet port
of the device.
C.Repeat steps A and B for each additional
device you want to connect to the switch.
Gigabit Ports
Gigabit ports come as 4-port 10/100/1000Base-
TX with Gigabit SFP socket combo, 4-port
1000Base-SX/LX/BX, or 2-port 10/100/1000Base-
TX with 2-port 1000Base-SX/LX/BX. These ports
can connect to network devices such as a
computer, printer, network video recorder
(NVR), network storage, or they can connect to
the network itself.
Wear an ESD-preventive wrist strap before
connecting to these ports.
Gigabit-SFP combo ports operate in “either/or”
fashion. This means that attaching to a 1 Gbps
SFP port renders the equivalent partner combo
port unavailable.
5 Apply AC Power
A.Connect the female end of the supplied AC
power adapter to the power receptacle on
the switch rear panel.
B.Connect the other end to a grounded 3-
pronged AC outlet.
Power-Up Sequence
When you apply AC power:
All
Link/ACTLEDs blink momentarily.
The
SystemLED goes ON.
LEDs for every port connected to a device
flash.
EX29000 SwitchInstallation Guide
Continued on next
page
