ZTTKR

Chrome thermostatic head with manual control

and built-in sensor for series 158...KR

The thermostatic valves automatically regulate the flow of hot water in the radiators according to the room temperature set on the

control knob, thus making each room independent. The use of valves with thermostatic heads allows the requirements of thermal

comfort to meet the needs of the user, thus obtaining significant savings in heating costs, as required by national and international

standards.

Temperature

adjustment

scale

Antifreeze

position

ConnectionSensitive element

ZTTKR8 ÷ 30°C8°CM30x1.5mmwith liquid

CHARACTERISTCS

Sensitive liquid element with built-in sensor.

Compact size and attractive design.

Hysteresis < 0.4 K.

Rotational limit selectors for pre-setting the adjustment range.

Low thermal inertia 18 min.

Head body in ABS.

Chrome finish.

Temperature adjustment range 8 ÷ 30°C.

Antifreeze position 8°C.

Standard connection M30x1.5mm

Maximum operating pressure 10 bar.

Maximum operating temperature 120°C.

Maximum differential pressure 1 bar.

Unalterable range -15°C ÷ +50°C.

Intermediate position “3” = 20°C.

Ring in CW 614 N UNI-EN 12164-98.

Dimensions (mm)

M30x1,5

Ø42

77 ÷ 82

3
