Operating instructions

8166189

2021-12e

[8166191]

Translation of the original instructions

© 2022 all rights reserved to Festo SE & Co. KG

1

Applicable Documents

All available documents for the product

è

www.festo.com/sp.

2Safety

2.1Safety instructions

–

Observe labelling on the product.

–Before working on the product, switch off the power supply and secure it

against being switched on again.

–

Store the product in a cool, dry environment protected from UV and corrosion.

Keep storage times short.

–

Store the product in ambient conditions without oils, greases and grease-dis-

solving vapours.

2.2Intended use

The mini slide is intended to be used for positioning payloads in combination with

tools.

The mini slide is only approved for slide operation.

Fig. 1:

Slide operation

2.3Training of qualified personnel

Work on the product may only be carried out by qualified personnel who can

evaluate the work and detect dangers. The qualified personnel have knowledge

and experience in dealing with electric drive systems.

3Additional information

–

Contact the regional Festo contact if you have technical problems

è

www.festo.com.

–

Accessories and spare parts

è

www.festo.com/catalogue.

4Product overview

4.1

Function

The mini slide converts the rotary motion of the mounted motor into a linear

motion of the slide. The screw drive converts the torque of the motor into a feed

force. The linear movement of the slide is precisely guided by the guide. Sensors

monitor end positions, reference position and intermediate position.

4.2Product design

1

2

3

4

56789101112

13

14

15

16

17

Fig. 2:Product design EGSC-BS

1

Through-hole and centring hole

2

Centring hole for attachment

component

3

Yoke plate

4

Hole for accessories

5

Threaded hole for attachment

component

6

Centring hole for attachment

component

7

Slide

8

Piston rod

9

Guide rail

10

Sealing air connection with filter

element

11

Interface for motor mounting kit

12

Drive hub

13

Slot for sensor bracket

14

Threaded hole for switch lug

15

Slot for profile mounting

16

Thread and centring hole for

direct fastening

17

Cylinder profile

5

Transport

NOTICE

Unexpected and unbraked movement of components

•Secure moving components for transport.

–Store and transport the product in its original packaging. Observe the weight,

the dimensions and the ambient conditions.

–

Take the centre of gravity of the product into consideration.

–Store and transport the product in a horizontal position.

6

Assembly

6.1Safety

WARNING

Risk of Injury due to Unexpected Movement of Components

For vertical or slanted mounting position: when power is off, moving parts can

travel or fall uncontrolled into the lower end position.

•

Bring moving parts of the product into a safe end position or secure them

against falling.

6.2Unpacking product

1.Open packaging.

2.Remove all transport materials, e.g. foils, caps, cardboard boxes.

3.Remove the product from the packaging and place it on the mounting surface.

4.

Dispose of packaging and transport materials.

6.3

Mounting the motor

Transverse load on the drive hub

When mounting the motor and motor mounting kit, do not exceed the maximum

transverse load F

R

of the drive hub, e.g. toothed belt tension when mounting the

parallel kit

è

12.1 Technical data, mechanical.

Axial kit EAMM-AParallel kit EAMM-U

Tab. 1:

Overview of motor mountings
