Seite 1/1

Assembly instructions (Original instructions)
8069056
1702b
[8069058]
†‡
Connection block
VABM-B10-25E
Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347-0
www.festo.com
1. Applicable documents
All available documents on the product www.
festo.com/pk
2. Safety
Switch off compressed air before mounting work.
Observe tigh
tening torques.
3. Intended use
Pneuma
tic linking of the valves.
4. Further inf
o
rmation
Accessories for VABM www.fes
to.com/catalogue
5. Scope of delivery
20518d_1
VABM-B10-25E-...
1 Connection block
2 Screw M4x50
1)2)
3 Seal
1)2)
4 Seal
1)
5 Blanking plug B-1/2
6 Blanking plug B-1/8
(1x)
(nx)
(nx)
(nx)
(3x)
(2x)
20518d_2
VABM-B10-25E-...-P3
1 Connection block
2 Screw M4x50
1)2)
3 Seal
1)
4 Seal
1)
5 Blanking plug B-1/2
6 Blanking plug B-1/8
(1x)
(nx)
(nx)
(nx)
(2x)
(1x)
6. Not in scope of d
e
livery
20520d_3
7 Solenoid valve
VUVS-... or
pneumatic valve
VUWS-...
1)
8 Screw set
1)
VAME-B10-25-S
only for VUVS-LK…-S,
with screws
ISO 4762-M4x40-8.8
(nx)
(nx)
20518d_13
1)
The number of screws , seals 2 8/3 4/ and valves 7 is dependent on the available
valve positions.
2)
Number = 2 x available valve positions
7. Mounting of blanking plugs 5
5
5
55/6
6
6
66
20518d_5
Screw in the blanking
plugs 5 6/ at the desired
position, as required.
Blanking plug [Nm]
58.5 _ 15 %
6 5.0 – 20 %
8. Mounting of connection block 1
1
1
11
20518d_6
Place connection block 1
on mounting surface (A).
Tighten screws (B).
9. Alignment of seal 4
4
4
44
20518d_11
For valves VUVS-L/LT...:
Place the seal 4 in the
depression of the valve 7
so it is positive-locking.
Observe channel
designation 1/3/5 or 1/3.
20
51
8d_12
For valves VUVS-LK...-S:
Place seal 4 on the
valve 7. Observe channel
designation 1/3/5 or 1/3.
Indexing hole (X) on the
valve 7 is:
– Only relevant for connection
block VABM-B10-25E-...
– Hidden after alignment
of the seal 4.
10. Mounting of valve 7
7
7
77
Information
Screws 8 can only be mounted with solenoid valves 7 VUVS-LK…-S.
Seals 3 can only be mounted for solenoid valves 7 with external pilot air
supply.
20518d_7
/Push screws 2 8 into the
drill holes of the valve 7.
Only screws 2 are loss-
protected.
Insert seals 3 into the
orifices (C). Rotating
movement required during
mounting.
Position valve 7 on the
connection block 1.
Check:
– Projection (D) is in the
slot (E)
– Valve 7 is aligned parallel
to the surface (F)
– Channel designations 1/3/5
or 1/3 agree with each
other.
Tighten screws 2 8/ .
3 Nm _ 20 %
1
1
5
6
2
4
1
5
6
2
4
A
B
7
4
3
C
E
1
F
5
6
7
4
D
315
3
3
2
/
8
7
4
C
315
X
X
X
7
8
