Assembly instructions (Original instructions)

8067428

1701c

[8067430]

†‡

Common supply manifold

VABM-B10-30-...-P53

Festo SE & Co. KG

Ruiter Straße 82

73734 Esslingen

Germany

+49 711 347-0

www.festo.com

1.Applicable documents

All available documents for the product www.f

esto.com/pk

2.Safety

Switch off compressed air before mounting work.

Observe tigh

tening torques.

3.Intended use

Pneuma

tic linking of the valves.

4.Further inf

o

rmation

Accessories for VABM www.fes

to.com/catalogue

5.Scope of delivery

21521d_1

VABM-B10-30-...-P53

1P manifold rail

2Blanking plug B-3/4

3Screw M5x60

1)2)

4Screw M5x40

1)2)

5Screw M5

(thread-cutting)

6Mounting bracket

7Seal

1)

8Distance ring

(1x)

(1x)

(nx)

(nx)

(8x)

(2x)

(nx)

(2x)

21521d_2

VABM-B10-30-...-P53-E

1P manifold rail

2Blanking plug B-3/4

3Screw M5x60

1)2)

4Screw M5x40

1)2)

5Screw M5

(thread-cutting)

6Mounting bracket

7Seal

1)

8Distance ring

(1x)

(1x)

(nx)

(nx)

(4x)

(1x)

(nx)

(1x)

6.Not in scope of d

e

livery

2148

1d

_9

9Solenoid valve

VUVS-... or

pneumatic valve

VUWS-...

1)

(nx)

2152

1d

_9

aJPush-in fitting (nx)

1)

The number of screws , seals 34/7 and valves 9 is dependent on the available valve

positions.

2)

Number = 2 x available valve positions

7.Mounting the mounting bracket 6

6

6

66

7a.VABM-B10-30-...-P53

2152

1d

_3

Define alignment of the

P manifold rail 1.

Information

The adjustment of the 0° and 30° angle of the common supply manifold 1

on a flat surface is dependent on the length of the silencer.

2152

1d

_5

Place both mounting

brackets 6 on the

P manifold rail 1.

Tighten all screws 5. If you

screw it in again, use the

threads already present.

7b.VABM-B

10-30-

...-P53-E

21521d_4

Define alignment of the

P manifold rail 1.

2152

1d

_6

Place the mounting

bracket 6 on the common

supply manifold 1.

Tighten all screws 5. If you

screw it in again, use the

threads already present.

8.Mounting the b

l

anking plug 2

2

2

22 and push-in fitting aJ

aJ

aJ

aJaJ

2152

1d

_7

Screw the blanking plug 2

in at the desired position,

as required.

Screw in the push-in

fitting aJ.

Information

One distance ring 8 each is required when mounting the push-in fittings

QS-G3/4-22 and CQ-3/4-22.

9.Mounting valve 9

9

9

99

Information

Screws 4 can only be mounted with solenoid valves 9 VUVS-LK…-S.

21521d_8

/Push screws 34 into the

drill holes of the valve 9.

Only screws 3 are

loss-p

r

otected.

Push seal 7 into channel 1

of the valve 9. Rotating

movement required during

mounting.

Place channel 1 of the

valve 9 onto the

opening (A).

Position the valve 9 on

the threads (B).

Tighten screws 34/.

1

1

2

2

3

3

5

5

7

7

6

6

9

3 Nm _ 20 %

3 Nm _ 20 %

6 Nm _ 20 %

3

/

4

6

5

1

1

5

6

9

7

AB

1

8

8

aJ

2

35 Nm

_ 10 %

8

aJ

1

4

4
