Assembly instructions (Original instructions)

8067325

1701b

[8067327]

†‡

Connection block

VABM-B10-30E

Festo SE & Co. KG

Ruiter Straße 82

73734 Esslingen

Germany

+49 711 347-0

www.festo.com

1.Applicable documents

All available documents on the product www.

festo.com/pk

2.Safety

Switch off compressed air before mounting work.

Observe tigh

tening torques.

3.Intended use

Pneuma

tic linking of the valves.

4.Further inf

o

rmation

Accessories for VABM www.fes

to.com/catalogue

5.Scope of delivery

2148

1d

_1

VABM-B10-30E-...

1Connection block

2Screw M5x60

1)2)

3Seal

1)2)

4Seal

1)

5Blanking plug B-3/4

6Blanking plug B-1/8

(1x)

(nx)

(nx)

(nx)

(3x)

(2x)

2148

1d

_2

VABM-B10-30E-...-P3

1Connection block

2Screw M5x60

1)2)

3Seal

1)

4Seal

1)

5Blanking plug B-3/4

6Blanking plug B-1/8

(1x)

(nx)

(nx)

(nx)

(2x)

(1x)

6.Not in scope of d

e

livery

2148

1d

_9

7Solenoid valve

VUVS-... or

pneumatic valve

VUWS-...

1)

8Screw set

1)

VABM-B10-30-S

only for VUVS-LK…-S,

with screws

(nx)

(nx)

21481d_14

ISO 4762-M5x40-10.9

1)

The number of screws , seals 28/34/ and valves 7 is dependent on the available

valve positions.

2)

Number = 2 x available valve positions

7.Mounting of blanking plugs 5

5

5

55/6

6

6

66

2148

1d_5

Screw in the blanking

plugs 56/ at the desired

position, as required.

Blanking plug [Nm]

535 _ 10 %

63.5 _ 20 %

8.Mounting of connection block 1

1

1

11

2148

1d

_6

Place connection block 1

on mounting surface (A).

Tighten screws (B).

9.Alignment of seal 4

4

4

44

2148

1d_8

For valves VUVS-L/LT...:

Place the seal 4 into the

depression of the valve 7

so that it is positive-locking.

Observe channel

designations 1/3/5 or 1/3.

2148

1d_1

3

For valves VUVS-LK...-S:

Place seal 4 on the

valve 7. Observe channel

designation 1/3/5 or 1/3.

Indexing hole (X) on the

valve 7 is:

–Only relevant for connection

block VABM-B10-30E-...

–Hidden after alignment

of the seal 4.

10.Mounting of valve 7

7

7

7 7

Information

Screws 8 can only be mounted with solenoid valves 7 VUVS-LK…-S.

Seals 3 can only be mounted for solenoid valves 7 with external pilot air

supply.

21

48

1d

_7

Push screws 28/ into the

drill holes of the valve 7.

Only screws 2 are loss-

protected.

Insert seals 3 into the

orifices (C). Rotating

movement required during

mounting.

Position valve 7 on the

connection block 1.

Check:

–Projection (D) is in the slot (E)

–Valve 7 is aligned parallel to the surface (F)

–Channel designations 1/3/5 or 1/3 agree with each other.

Tighten screws 28/.

6 Nm _ 20 %

2

/

8

1

1

5

6

2

3

4

1

5

6

2

3

4

A

B

7

4

3

C

E

1

F

7

4

D

51

3

6

5

7

7

4

C

51

3

X X

8
