Seite 1/2
FLIR Ariel
TM
Corner Camera
Superior Low Light Performance in 5MP and in 8MP with Edge AI Video Analytics
www.ir.com/products/ariel-corner-camera
For technical or sales support, please visit: www.flir.com/about/general-inquiries
Key Features
• Provides total room coverage due to unique corner mounting,
ligature-free, housing, and discrete infrared illumination
• Ensures forensic detail in 5 MP or 8 MP video stream—even in
harsh lighting conditions—thanks to superior low-light performance
and wide dynamic range quality
• 8 MP Corner Camera with Edge AI Video analytics for Abandoned
Object, Intrusion Detection, Camera sabotage, Trip wire, Loitering,
Object removal, Object counting, Stopped vehicle, Face detection
• Offers a complete solution with FLIR United VMS as well as open
integration with various of 3rd party VMSs
Main Applications
• Commercial buildings and close area surveillance inside critical
infrastructure sites
• Areas that require complete coverage from a single camera
• 24/7 monitoring at correctional institutions, healthcare facilities,
building lobbies and elevators
SPECIFICATIONS
Specications subject to change. For the most up-to-date specications, please visit .ir.com
CC-3405-01-I CC-3408-01-IA
Image sensor 1/2.7” 1/2.3”
Sensor resolution 5 MP 8 MP
Scanning mode Progressive
Lens type
2.1 mm, F/2.0,
139.1° HFOV × 101.65° VFOV
@ 2592 × 1944
2.8 mm, F2.2,
132.9° HFOV × 98.1° VFOV
@ 4000 × 3000
Digital slow shutter (DSS) 1/4 (1/4) – 1/60 (50) NTSC (PAL)
White balance AUTO
Automatic gain control
(AGC)
Yes
Backlight compensation
(BLC)
Yes, ON/OFF in linear mode
Shutter WDR 130 dB
Noise reduction 3DYes
Tamper detection Yes
Privacy zones Yes
Video motion detection Yes
Day/Night mode Yes
Mechanical IR cut lter Yes
Signal to noise ratio ±45 dB
Camera
Automatic electronic
shutter (AES)
1/1 to 1/32,000
Sensitivity B/W: 0.036; Color: 0.172 B/W: 0.077; Color: 0.37
Video
Compression Enhanced H.265 main prole + Enhanced H.264
main/high/baseline Prole + MJPEG
Max performance HDR:
2592 × 1944 + 800 × 600,
@30 fps
2048 × 1536 + 800 × 600,
@30 fps
HDR:
3328 × 2496 + 720 × 480 +
640 × 480, @27 fps
3328 × 2496 + 720 × 575 +
640 × 480, @25 fps
Linear:
3328 × 2496 + 720 × 480 +
640 × 480, @30 fps
3328 × 2496 + 720 × 576 +
640 × 480, @25 fps
Resolution range Scalable from SVGA to
5 MP
Scalable from SVGA to
8 MP
Bandwidth Congurable between 64 kbps and 20 Mbps
Rate control LBR, CBR, VBR
SD card recording microSD/microSDHC/microSDXC size up to 1 TB
Network
Network protocols IPV4/6, HTTP, HTTPS, UPnP, DNS, NTP, RTSP, RTP, TCP,
UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, SNMP, QoS,
TLS, SMTP, FTP, DDNS, PPPoE, RTCP
Ethernet 10/100 mbps 10/100/1000 mbps, auto
sensing, half / full duplex
Remote conguration Via web browser or supported VMS
Firmware upgrade Flash memory for upgrade of camera rmware
over the network
Supported web browser Firefox, Chrome, Edge, Safari
Security Password protection
IP address ltering
TLS/HTTPS
IEEE 802.1X network access control
Digest authentication
Password policy
Protect from multiple failure login
ONVIF support Proles S, G, M, and T
This product is subject to United States export regulations and may require US authorization prior to export,
reexport, or transfer to non-US persons or parties. Diversion contrary to US law is prohibited.
For assistance with conrming the Jurisdiction & Classication of Teledyne FLIR, LLC products, please contact
exportquestions@ir.com. ©2025 Teledyne FLIR, LLC. All rights reserved.
Revised 03/21/25
FLIR_Ariel_5MP-8MP_Corner_Cameras_Datasheet _en-US-LTR 25-0137-INS
For technical or sales support, please visit:
www.flir.com/about/general-inquiries
FLIR Ariel
TM
Corner Camera
Superior Low Light Performance in 5MP and in 8MP with Edge AI Video Analytics
www.ir.com/products/ariel-corner-camera
Specications subject to change. For the most up-to-date specications, please visit .ir.com
For more information
about FLIR Ariel
™
Corner Camera please
scan or visit:
ORDERING INFORMATION
Model Description
CC-3405-01-I FLIR Ariel
™
5 MP Corner Camera
CC-3408-01-IA FLIR Ariel
™
8 MP Corner Camera with Edge AI Video Analytics
CC-3405-01-I CC-3408-01-IA
Audio
Bidirectional audio Line in and Microphone built in, G.711/G.726/AAC/LPCM,
Line out
Alarm
Input 2 dry alarm contacts, 5 V with 10 KΩ pull up, 100
mA @ room temperature
Output 1 relay contact max. 350 V DC/AC, 130 mA
Physical
Enclosure Metal IK10 vandal resistant/IP66
Dimensions 150 × 82 × 52 mm (5.9 × 3.23 × 2.05 in)
Unit weight Net: 1.01 kg (2.22 lb)
Gross: 1.35 kg (2.97 lb)
Net: 1.03 kg (2.27 lb)
Gross: 1.39 kg (3.06 lb)
Electrical
Input voltage PoE IEEE802.3af (class 0), 12 V DC, 24 V AC
Power consumption 12.95 W
Power connection RJ45, DC, AC
IR Illumination
Distance 15 m (49.2 ft) 10 m (32.80 ft)
Angle of illumination Full 90°
LED type High-efciency SMD
Peak emission wavelength 940 nm 850 nm
Environmental
Operating temperature -30°C to 55°C
(-22°F to 131°F)
-10°C to ~55°C
(14°F to ~131°F) – IR off
Heater not required
Storage temperature -20°C to 70°C (-4°F to 158°F)
Humidity 10%–90% (non-condensing)
Warranty and Regulatory
Warranty According to FLIR RMA Policy and Process
Notice document
USA FCC Part 15 (subpart B, class A, ICES-003)
International CE marked, EN 61000-6-3, EN 62368-1, EN 50130-4, CB
62368-1, LVD (CoC), RoHS, RCM, WEEE, ISTA-3A
MTBF (hours) 526,279 (30°C); 149,537 (60°C)
Shock and vibration IEC 60068-2-64: 2008
Bump and vibration IEC 60068-2-27: 2008
SPECIFICATIONS, CONT.
