使用操作

磁吸式充电操作

本手电采用专利磁吸式充电，标配USB数据线和磁吸式充电连接器，最大充电电流1000MA充电时用USB数据线，

将USB供电设备（包括电脑USB、车载USB、手机适配器USB等）和磁吸式充电连接器连接，再将磁吸式充电连接

器的磁吸公头和手电筒的磁吸母头连接即可为手电筒充电。

磁吸式充电连接器

• 品名-光色）：灯珠-暖白（)

• 尺寸：×15mm×11.5mm45mm

• 重量：含电池）6g（

LED（30143000K

vary slightly during actual use due to battery type, individual usage habits and environmental factors.

KLARUS is a member of PLATO, participating in and helping to develop the ANSI/NEMA FL1 standard of

measurement. Product testing data is in accordance with these internationally recognized scientific

standards.

We recommend that you use a reliable, high performance KLARUS charger to charge batteries separate from

the flashlight, should you not wish to charge it directly

Operations

Magnetic-ChargingExtendedReachTacticalFlashlight

withProgrammableInterface

XT12GT

Features

• MagneticChargerwithselflocatingbase;Programmableuserinterface;Extremespotlightcapability; -

Ruggedreliability;Patentedfeatures

•

• Features CREE LED XHP35 HI D4; Illuminates up to 603 meters

• Ready for duty with included KLARUS 18GT-36 18650 battery (same as featured in TESLA electric cars,

3600 mAh) for Max 1600 Lumens output

• Easy Interface: One-Touch Strobe; One-Touch Turbo; One-Touch Low; Mode memory; SOS; Capacity

indicator, Convenient Magnetic Recharging; ITS temperature control; Quick mode change

• Compact and light (Bezel 45.2mm(1.78") (D), Body 25.4mm(1")(D), Length 161.5mm(6.36")), Weight 159g,

(5.60oz) w/o battery

• Patented Dual Tactical Tail Switch Control; One-hand tactile control; the next evolution in flashlight control UI

• Two Interfaces: Tactical Setting; Outdoor Setting

◇Tactical Setting: Classic KLARUS XT series control. One-Touch Turbo; One-Touch Strobe; versatile in all

tasks

◇Outdoor Setting: Specially designed for the wilderness. One-Touch Low; One-Touch Turbo; Multiple output

levels with memory, SOS function; suitable for all needs in Hunting, Hiking, Camping or Search and Rescue

• Convenient Magnetic Charger; Self-locating Base; Magnetic attachment; Sealed agains water, dirt, sand

• Magnetic Charger included: Compact (45mm x 15mm x 11.5mm)(1.71" x 0.59" x 0.45");

Lightweight (6g.) (0.21oz) ; Micro-USB connector; includes LED locator light (10 Lumen, 110 min.)

• 1A recharging current; quickly back in action

• Intelligent Digital Charging module; monitors charging progress for safe and fast recharging with over-

charging protection

• ITS temperature control, real time monitor and auto-adjust output levels to keep LED and crucial component

safe for the best balance of performance and equipment safety

• Capacity Indicator alerts on remaining battery capacity any time

• Springs at bezel and tail resist shock and drop damages

• Reverse Polarity Protection; eliminates damage from incorrect battery install

• Aero-space Aluminum alloy body with CNC technology; Military spec hard anodizing (HA III); lightweight and

robust

• Stainless bezel ring offers protection for crucial components

• Hardened Mineral Glass lens with AR coating; scratch resistant

Specifications

• Utilizes CREE XPH35 HI D4 LED with a lifespan of up to 50,000 hours

• Tactical Setting as factory default

Notice: Only when using KLARUS 18GT-36 3600mAh battery or the same batteries of the other brand,

the Max output could be up to 1600LM; When using the normal 18650 battery with PCB protection or 2 x

CR123A batteries, the Max output could be only up to 1300LM

• Working voltage: 2.5V-8.4V

• Compatible Batteries: 1x 18650 battery with PCB protection or 2 x CR123A batteries

• Charging time: Depends on the battery capacity

Formula: charging time= (capacity of battery/1000mA+1H)

• Body colour: Black

• Reflector: Smooth reflector

• Switch type: Dual Tactical Tail Switch

• Dimension: (Head)45.2mm(1.78") × (Body)25.4mm(1") × (Length)161.5mm(6.36")

• Net weight: 159g (5.60oz) (Excluding battery)

• Material: Aircraft-grade aluminum 6061-T6, Type III hard-anodized

• Waterproof: IPX-8 (underwater 2 metres)

• Lens: Toughened ultra-clear glass with anti-corrosion AR coating

• Included accessories: USB charging cable x1, lanyard x1, spare o-ring x1, 18650 battery x1, holster x1,

clip x1, Magnetic Charger x1

Notice: The above data has been measured in accordance with international flashlight testing standards

ANSI/NEMA FL1 using one KLARUS 18GT-36 3600mAh battery under laboratory conditions. The data may

Compact size for ease of carry and use

Magnetic Charging

This flashlight utilizes patented magnetic charging with the included USB cable and the Magnetic Charger for

a max charging current of 1000 MA. Connect the USB cable between any USB outlet (computers, vehicles or

mobile phone chargers, etc.) and the Magnetic Charger; connect the Magnetic Charger to the flashlight's

charging receptacle to begin charging the flashlight.

MagneticCharger

• LED3014WarmWhite3000K

• Size45mmx15mmx115mm (1.71" x 0.59" x 0.45"): .

• Weight6g(0.21oz)winternalbattery: (/ )

• BatteryGJ35121832mAhLithiumIon: - -

• Current5V:

• TimetoCharge3H :

• MaterialPolymer:

• SurfaceCoating:

• WaterproofNA: /

• LensPCFrosted:

• SwitchOnOff: /

• AccUSBCableKey ring.: ,

Note: , , Theincludedcompactandlightweightmagneticchargerinadditiontochargingtheflashlightwillalso

actasakeychainLEDlightPuttheswitchtoONorOFFwillturnonorturnofftheLEDlightrespectively . "" "" ,

thislightcanbeoperatedwhilechargingisinprogressTheinternalLiionbatteryforthechargerwillauto . - -

rechargewhiletheflashlightisbeingcharged .

Battery Remaining Indicator

• When flashlight is initially turned on, the battery indicator light on the side switch will flash for 5 seconds then

turn off

• Green indicator : 70%-100% charge

• Orange indicator: 30%-70% charge

• Red indicator: less than 30% charge

• When the power is less than 10%, the indicator light will illuminate RED and then flicker to alert user that

capacity is critical

Note: The battery indicator status works only if you are using a 18650 Li-ion battery.

Smart ITS Temperature Control System

When the flashlight is in high light mode, brightness will be automatically adjusted according to the

temperature of the flashlight body to protect the LED and internal components and ensure safety and stability.

Charging indicator light

• During charge: The indicator light on the switch is red.

• Charging is complete: The indicator turns green.

• Abnormal condition: The indicator turns orange and flickers;

please switch off power and check before charging again

Battery replacement

Unscrew the tail from the flashlight body , insert batteries with

the positive indicator (+) facing in the direction of

the flashlight body and then screw the tail back on

Usage and Maintenance

• The flashlight's surface will increase in temperature during use, especially during periods of higher lumen output.

The maximum safe operating surface temperature of the flashlight is 60 /140 F℃

• Please fully charge battery before initial use. Included battery is charged to less than 50% as a safety measure and

will not power the flashlight at full specification without charging

• Do not shine light directly into eyes

• Use only quality brandname batteries

• Remove batteries when stored for extended periods

• Use soft brush and soapy water to clean the body of the light

• To maintain waterproof condition, please lubricate the O-ring with a silicone based O-ring lubricant and replace

worn O-rings as needed. (The lubricant can be found in the plumbing section in most hardware stores, confirm with

the store that it is silicone based)

Warranty

• KLARUS guarantees the flashlight against defects in material and workmanship. Flashlight products that are

found to be defective under normal use within 5 years of the proof of purchase date will be repaired or

: - ()

replaced without charge

• This warranty does not cover damage caused by accident, unreasonable use or product alteration. Failure to

follow the general maintenance directions could result in damage to your flashlight that may not be covered

by the KLARUS warranty

Limited lifetime warranty

If problems develop after 5 years from the date of purchase, KLARUS will charge for parts only. The total repair fee

will be assessed according to the cost of the replacement materials. If damage to the light is substantial, KLARUS will

contact the customer via the distributor with a quote. The customer can then decide whether to proceed with the

repairs or not. Freight will be paid by distributor or customer

Warranty Procedure

• If this flashlight does not perform to the specification, the product will be repaired or replaced as described above.

• Please contact your original KLARUS dealer for replacement and repairs

• If the warranty issue cannot be resolved by the dealer, please contact KLARUS at info@klaruslight.com for

assistance. Please provide the following information to expedite the process:

1) List the series number on the light

2) Include a detailed description identifying the issue, accompanied by pictures or a short video demonstration

if necessary

3) Provide the name and store of the dealer you made the purchase from; and a copy of the proof of purchase

•

• 电路工作模式：降压

• 工作电压：5V

• 充电时间：3H

• 材料：塑胶

• 表面处理工艺：喷橡胶漆

• 防水标准：无

• 镜片类型：雾面PC

• 开关类型：拨动

• 配件：数据线 钥匙圈USB

备注：本手电标配磁吸式充电连接器，体积小巧，便于携带，不仅可做便捷式磁吸充电连接器使用，还可做钥匙灯

使用，拨动磁吸式充电连接器上的开关至端即可打开灯，拨动开关至端即可关闭灯。还可充电持续ONLEDOFFLED

使用，在连接端口给手电筒充电的同时，磁吸式充电连接器内部也会自动为内置锂电池充电。USB

温控系统

智能温控系统，在最高亮时智能温控系统会根据手电筒的温度来调节手电亮度，最大限度的保护及内部元器LED

件，更可靠更安全，同时增强握持温度舒适度

电量指示

• 开机后侧按键指示灯显示秒，秒后关闭55

• 绿色，表示剩余电量70%-100%

• 橙色，表示剩余电量30%-70%，

• 红色，表示剩余以下30%

• 电量在低于时指示灯红灯闪烁，提示用户电量即将耗尽 10%

注：此电量指示功能只针对锂离子电池18650

充电指示

充电中，指示灯为红灯；充满电后，指示灯为绿灯；充电异常时指示灯黄色闪烁

电池安装

使用及维护

• 手电在使用过程中，手电表面温度在以下属于正常情况，请放心使用60℃

• 充电电池出厂时只有以下电量，直接使用不能达到最高亮度和正常续航时间，首次使用请将电池充满50%

• 为达到最佳防水性能，请定期检查防水圈的完整性，并请适量涂抹润滑硅脂于防水圈上以延长其使用寿命。OO

如圈损坏，请及时更换原厂圈以确保您所使用之产品的优异防水性能OO

• 请勿将手电筒的光线直接照射人类或动物的眼睛

• 手电筒不用时，可将筒尾扭松，避免误操作

• 长时间不使用手电筒时，请将电池取出，并妥善存放

电池：-聚合物锂电池*GJ35121832mAh1

保修

• 天保换期：自售出之日起天内，在正常使用情况下，出现产品质量问题，客户可选择更换新品或维修服务， 1515

要求更换时，所换产品应为返修产品同型号同规格的新品；如同型号同规格的产品停止生产时，则调换不低于原

产品性能的同品牌产品

• 年免费保修期：自售出之日起年内，用户在正常使用情况下，出现手电主体质量问题，可享受免费维修服务55

• 终身有限保修：超过年免费保修期外，手电主体提供有偿保修，费用以实际更换材料费用为准，不另收取人工费5

• 磁吸式充电连接器提供年质保1

模式切换

User setting 1: Tactical Setting

One-Touch Strobe, One-Touch Turbo

Primary Switch

Press

Press down

Momentary-ON

Turbo

Release

Depress then release

Turn off

Mode Switch

Turn off

Press

down

Long depress

(> 2 seconds)

Strobe

Keep strobe

Release in 2 seconds

Quit strobe

Click

Turbo

When ON

Click

Turbo

High

Low

Cycle

Mode Switch

Press down

Low

Release in 1 second

Turn off

Long depress

(>1 second)

Click

Keep LOW mode

Long depress

for 1 second

Turn off

User setting 2: Outdoor Setting

One-Touch Turbo, One-Touch Low, SOS

Primary Switch

Press

Press down

Momentary-ON

Turbo

Release

Depress then release

Turn off

Turn off

Turbo

Medium

High

Low

Cycle

When OFF

Long depress

(> 2 seconds)

Click

Keep strobe

When ON

Long depress

Strobe

When

Switch OFF

Primary

When

Switch ON

Primary

Click

Quit strobe

Turbo

Medium

High

Low

Cycle

磁吸式充电可编程远射战术手电

XT12GT

特点

• 快速准确定位的磁吸式充电可编程远射充电战术手电，超强远射，性能强悍，专利保护

• 搭载美国最新 聚光性能更强，射程高达米

• 标配特斯拉同款- 电池，高亮流明18GT363600mAh186501600

• 功能全面强悍:一键爆闪，一键极亮，一键低亮，电量指示，磁吸式便捷充电，智能温控， 模式自由切换SOS，ITS

• 体积小巧，轻便(头部直径筒身直径.长度), 重量(不含电池)45.2mm，254mm，161.5mm159g，

• 尾部专利战术双开关，完全单手盲视操作，黑暗中准确定位，达到方便使用的新境界

• 搭载两种操作模式：战术模式，户外模式

◇模式一：战术模式，秉承系列的经典操作方式，应对各种使用环境KLARUS XT

◇模式二：户外模式，专为户外场景而设计，在黑夜中可快速定位一键低亮或一键极亮，配合多档位亮度、SOS

求救功能等，更使得能够应对复杂多变的环境，很好地兼顾了狩猎、搜索、徒步、露营和紧急求XT12GT

救等使用场景

• 方便易用的磁吸式充电口设计，自动吸附快速对位，有效防水，防尘，防泥沙

• 标配磁吸式充电连接器，体积小巧（），重量（，含电池）， 充电接口 45mm×15mm×11.5mm6gMicroUSB

可用于小范围辅助照明，内置锂电，亮度流明，续航小时分钟10150

• 充电电流高达充电更快，使用更方便1A，

• 智能数字充电模块，实时监测充电进度，有效防止电池过充，更快速，更安全

• 最新智能温控系统，实时监控内部温度变化并平滑调整最高亮度输出，最大限度的在保护及内部元器件安ITSLED

全的基础上提升照明性能，达到产品性能和安全性的良好平衡

• 智能电量指示功能，随时查看剩余电量，使用时间自由掌控

• 头尾双弹簧设计，防震、防摔、抗冲击

• 防反接设计，防止电池装反对电路造成危害

• 航天级铝合金材质，机加工外壳，军工三级硬质阳极氧化处理，耐磨更轻更坚固CNC

• 灯头不锈钢压圈设计，更好的保护核心部件

• 主灯镜片采用钢化玻璃，镀膜，防刮耐磨AR

规格

• 采用 寿命长达 小时CREEXHP35HID4LED，50000

• 出厂设置为战术模式 , 共4种亮度模式，2种闪烁模式

备注：只有使用 - 锂电池或相同放电性能的锂电池时，最高亮度可以达到KLARUS18GT363600mAh18650

1600186502xCR123A1300流明，使用普通锂电池或电池时，最高亮档只能达到流明

• 工作电压 2.5V-8.4V

• 可兼容电池：CR123A电池×2 18650电池(带保护电路)×1 ,

• 充电时间：根据电池容量决定　公式：充电时间＝(电池容量/1000mA+1)h

• 反光杯：光面光杯

• 开关类型：战术尾部双开关

• 尺寸：头直径45.2mm×身直径25.4mm×总长161.5mm

• 重量：159g(不含电池)

• 材料：航空铝 6061-T6经过军规三级硬质阳极氧化处理，

• 防水：IPX-8级防水设计

• 镜片：钢化玻璃，镀AR膜，防刮耐磨

• 配件：USB充电线*1 手绳*1 O型圈*1 18650电池*1 布套*1 抱夹*1 磁吸式充电连接器*1 , , , , , ,

备注：以上参数是按照国际手电筒测量标准ANSI/NEMA Fl1所述之方法测量所得，所使用电池为1节KLARUS

18GT-36 3600mAh 18650电池，实际数据可能会随着不同电池或使用环境而产生影响。KLARUS是美国手电行

业协会(PLATO)的成员，参与制定和优化ANSI/NEMA FL1手电标准，产品测试数据标准科学。

如需使用充电器充电，建议使用KLARUS凯瑞兹高可靠性充电器。

CREEXHP35HID4LED603，

模式战术模式1:

一键爆闪，一键极亮

战术开关

轻触

按下

瞬亮

进入极亮档

松开

按下松开

关机

关机

MODE开关

按下

按下超过秒2

爆闪

锁定爆闪

2秒内松开

退出爆闪

单击

极亮

开机状态

单击

极亮

高亮

低亮

循环

模式户外模式2:

一键极亮，一键低亮, SOS

战术开关

轻触

按下

瞬亮

进入极亮档

松开

按下松开

关机

关机

MODE开关

按下

按下超过秒1

低亮

1秒内松开

退出低亮

锁定低亮

低亮高亮

中亮

极亮

循环

长按秒1

关机

单击

关机状态

开机状态

超过秒2

锁定爆闪

退出爆闪

单击

长按

爆闪

战术开关 / 开

单击

极亮

中亮

高亮

低亮

循环

90902

603

1

142002.4

续航时间(h)

最高光强度(cd)

高亮档射程(m)

防跌落(m)

防水级别

400

100

10

1600

ANSI/NEMA FL1

亮度(LM)

高亮

中亮低亮

爆闪

IPX8级防水（水下2m）

极亮

SOS

1.2

1600

100

424

+

-

战术开关

关机状态下，长按秒不放10

指示灯开始红/绿交替闪烁

(进入模式切换状态)

请勿松开开关MODE

按下战术开关切换

从当前模式切换到另外一个模式

MODE开关

User setting Change

When OFF

Long depress 10 seconds

Don't release the

mode switch

Press down

primary switch

the

Change to the other mode from current mode

Mode Switch

Indicator light will

blink to indicate

ready to program

Primary Switch

High

Medium

Low

Strobe

IPX8(under water 2m)

Mode

Specification

ANSI lumens (LM)

Runtime(h)

Peak beam intensity(cd)

Max beam distance(m)

Impact resistance(m)

Waterproof

90902

603

1

14200

2.4

400100101600

SOS

1.2

1600100

42

4

Turbo

按下超过秒3

SOS

单击

退出SOS

Long depress

(>3 second)

SOS

Click

Quit SOS

战术开关 / 关

WebsiteFacebook

KLARUS LIGHTING TECHNOLOGY CO., LIMITED

Office Address: Room 521-525, Zhihuigu Innovation Park, 1010 Bulong

Road, Longhua District, Shenzhen City, 518131,China

Factory Address: 5/F, No.26 Building, Niulanqian Industrial Park,

Longhua District, Shenzhen City, 518131, China

EmailPhone:info@klaruslight.com:+86-755-27700110

Website :www.klaruslight.com

深圳市凯瑞兹电子科技有限公司

写字楼地址：深圳市龙华新区布龙路号智慧谷创新1010

园大楼521-525

工厂地址：深圳市龙华新区民治牛栏前工业区栋楼265

邮编：518131

电话：+-- 8675527700110

网站：..wwwklaruslightcn

：邮箱info@klaruslight.com

关注微信

淘宝购买

进入官网

京东购买
