INSTRUCTION MANUAL
FRANÇAIS pg. 17
ESPAÑOL pg. 9
Electronic
AC/DC Voltage Tester
• MODERN
SOLID-STATE
DESIGN
• LOW IMPEDANCE
• DOES NOT
USE A BATTERY
• INTEGRATED
TEST LEAD
HOLDER
ENGLISH
ET60
3
m IP54
5001748
2
GENERAL SPECIFICATIONS
Klein Tools ET60 is a solid-state, low impedance, electronic voltage
tester. It measures AC/DC voltages up to 600V. The ET60 does
not
require batteries; it is powered by the applied voltage.
• Operating Altitude: ≤ 6562 ft. (2000 m)
• Relative Humidity: <90% non-condensing
• Operating Temperature: 5°F to 113°F (-15°C to 45°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Battery Type: None (powered by applied voltage)
• Dimensions: 5.67" x 2.35" x 1.44" (144 x 59.8 x 36.5 mm)
• Weight: 3.2 oz (92 g) without test leads
• Calibration: Accurate for one year
• Standards:
Conforms to: EN61326-1:2013,
EN61326-2-2:2006, EN61010-1:2010,
EN61010-2-030:2010, EN61010-031/A1:2008
• Pollution degree: 2
• Drop Protection: 9.8 ft. (3m)
• Ingress Protection:
IP54 (except test lead jacks, see WARNINGS)
• Safety Rating: CAT IV 600V, Class2, Double insulation
CAT IV: Measurement category IV is applicable to test and
measuring circuits connected at the source of the building’s
low-voltage MAINS installation.
• Electromagnetic Environment: IEC
EN61326-1:2013
. This
equipment meets requirements for use in basic and controlled
electromagnetic environments like residential properties,
business premises, and light-industrial locations.
Specifications subject to change.
ENGLISH
3
ELECTRICAL SPECIFICATIONS
• Voltage Level Indicators: 12V, 24V, 48V, 120V, 208V, 240V,
277V, 480V, 600V
• Voltage Type Indicators: DC Positive, DC Negative,
both DC polarities "on" indicates AC
• AC Frequency: 45Hz to 66Hz
• Maximum Measurable Voltage:
600V RMS (displayed by LEDs)
• Minimum Voltage Detectable:
Approx. 10V AC RMS or 10V DC
• Input Impedance:
16kΩ at 120V (Inherent Low Impedance Testing)
• Loop Current: 6mA to 9mA at 120V
• Usage Duty Cycle (Above 240V):
30 seconds continuous use
followed by 240 seconds (4 minutes) recovery time
• Accuracy: LEDs illuminate fully typically at approx. >90%
of indicated voltage, and will illuminate partially when
approaching this value
Specifications subject to change.
WARNINGS
To ensure safe operation and service of the meter, follow these
instructions. Failure to observe these warnings can result in
severe injury or death.
• Before each use verify tester operation by measuring a known voltage.
• Never use the tester on a circuit with voltages that exceed the
category based rating of this tester.
• Do not use the tester during electrical storms or in wet weather.
• Do not use the tester or test leads if they appear to be damaged.
• Use only with CAT IV rated test leads.
• Ensure tester leads are fully seated, and keep fingers behind
the finger guards and away from the metal probe contacts
when making measurements.
• Use caution when working with voltages above 25V AC RMS
or 60V DC. Such voltages pose a shock hazard.
• Always adhere to local and national safety codes. Use personal
protective equipment to prevent shock and arc blast injury
where hazardous live conductors are exposed.
• This is a Low Impedance (LoZ) tester, it should not be used in
circuits or situations where damage or adverse effects may be
caused by a ~ 16kΩ load.
• Tester is IP54 dust & water resistant. Following any contact
with water, thoroughly dry tester and test lead jacks prior to
subsequent use.
