Kuzco Beacon FM13120 Bedienungsanleitung

Lies die bedienungsanleitung für Kuzco Beacon FM13120 (1 Seiten) kostenlos online; sie gehört zur Kategorie Beleuchtung. Dieses Handbuch wurde von 2 Personen als hilfreich bewertet und erhielt im Schnitt 4.5 Sterne aus 6 Bewertungen. Hast du eine Frage zu Kuzco Beacon FM13120 oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

INSTALLATION SHEET

FM13120

LED Flush Mount

START FROM HERE

Please Note:

•All Kuzco LED fixtures come with pre-wired LED module(s).

• Unless instructed to do so, please do not touch any part of the LED module(s) as any

unnecessary contact with the module could cause permanent damage.

• For dimming, an ELV (Electronic Low Voltage) type of dimmer is required.

•

Make sure power is completely off at the fuse box.

•

Have your fixture installed by a qualified licensed electrician

•

Prepare everything in a clear area.

•

Wear gloves at all times during this installation.

•

Read instructions carefully before you start assembly.

•

Keep this instruction sheet for future reference.

Technical Support: 1-877-452-6858

19054 28th Avenue Surrey, BC Canada V3S 6M3

T: 604 538 7162 TF: 1-855 85 KUZCO F: 604 538 7196

W: kuzcolighting.com

20170123

1.

2.

Remove the fixture from its original packaging. Next,

remove the mounting plate from within the (1c)

canopy by un-threading the two nuts .Se-(2a) (2b)

cure the mounting plate to the junction box with (1c)

screws (1e).

Connect all wires correctly black to black “L”, white

to white “N” and the ground wire with provided

marettes from the hardware package. Align the (1b)

threaded studs with the holes on the surface of (1d)

the canopy . Next, push the canopy to the (2a)(2a)

mounting plate thread on the two nuts on (1c)(2b)

to the threaded studs . This will secure the (1d)

canopy to the mounting plate.

Once this is complete, place the diffuser into (2c)

the fixture. Gently turn the diffuser clockwise (2c)

onto the canopy until it locks. (2a)

You have now completed the installation of your

fixture, enjoy.

3.

4.

1a.

1b.

1e.

2b.

2a.

1c.

1d.

2c.
