Contents

•Weatherproof IR dome camera

•Mounting screws x 4

•60ft. BNC / power extension cable

•BNC female / RCA male adapter

•Power adapter

Features

•Advanced Sony Super HAD™ II image sensor

•Video image processor produces sharp and clear video at

600TV lines of resolution

•Night vision up to 50ft. (15m) away in total darkness*

•ClearNight imaging technology ensures clear night vision and

improves recording efficiency up to 30%

•3.6mm wide angle lens for wide area coverage (80° FOV)**

•IP66 rated aluminum housing for indoor / outdoor

installations***

Disclaimers:

* Infrared illumination range under ideal conditions. Actual range and clarity may vary depending on

scene/object reflection and camera application.

** Field of View, diagonal.

*** Not intended for submersion in water. Installation in a sheltered location recommended.

Warning/Caution

•Read this guide carefully and keep it for future reference

•Follow all instructions for safe use of the product

•Use the camera within given temperature, humidity, and

voltage levels noted in Camera Specifications

•Do not disassemble the camera

•Do not point the camera directly towards the sun or a source of

intense light

•Use only the supplied regulated power supply. Use of a non-

regulated, non-conforming power supply can damage this

product and voids the warranty

•The supplied extension cable is rated for surface mounting only

•Cables for in-wall / floor-to-floor installations are sold

separately

Installation Tips

•Point the camera where there is the least amount of obstructions

(i.e. tree branches)

•Install the camera in a location that is difficult for vandals to

reach

•Secure cabling so that it is not exposed or easily cut

•Camera rated for outdoor use. Installation in a sheltered

location recommended

WARNING: A REGULATED UL / CSA APPROVED power supply is

REQUIRED for use with this camera. Use of a non-regulated, non-

conforming power supply can damage this product and voids the

warranty.

Camera Specifications

* IR Illumination Range under ideal conditions. Objects at or beyond this range may be partially or

completely obscured, depending on the camera application.

** Not intended for submersion in water. Installation in a sheltered location recommended.

Dimensions

Copyright © 2011 Lorex Technologies Inc.

As our products are subject to continuous improvement, Lorex reserves the right to modify product design,

specifications and prices, without notice and without incurring any obligation. E&OE

Image Sensor1/3” Sony Super HAD™ II

Video FormatNTSC

Effective PixelsH: 768 V: 494

Resolution600 TV Lines

Scan System2:1 Interlace

Sync SystemInternal

S / N Ratio50dB (AGC Off)

IrisAES

AES Shutter Speed1/60 ~ 1/100,000 sec.

Min. Illumination0.2 Lux without IR LED

0 Lux with IR LED

Video OutputComposite 1.0Vpp @ 75ohm

Lens / Lens Type3.6mm F2.0 / Fixed

FOV (Diagonal)80°

TerminationBNC Type

IR LED Qty / Type14 pieces / 850nm

Night Vision Range*50ft. / 15m

Power Requirement12V DC ±10%

Power ConsumptionMax. 250mA (w / IR)

Operating Temp. Range14° ~ 122°F / –10° ~ 50°C

Operating Humidity Range< 90% RH

Environmental Rating**IP66

Weight (including stand)0.8lbs. / 0.4kg

95mm / 3.8"

88mm / 3.5”

Product Information

User Manuals

Quick Start Guides

Specification Sheets

Software Upgrades

Firmware Upgrades

LDC6051

SUPER RESOLUTION WEATHERPROOF

NIGHT VISION DOME CAMERA

FOR SUPPORT AND INFORMATION,

VISIT WWW.LOREXTECHNOLOGY.COM

QUICK START GUIDE

English Version 1.0
